StarTech.com 10/100 Mbps Ethernet Single Mode WDM Fiber Media Converter Kit SC 20km - WDM (Wave Division Multiplexing) Technology - a (ET90110WDM2)

(No reviews) Write a Review
$594.99
$564.74
(You save $30.25 )
SKU: ET90110WDM2
UPC: 65030846271
Availability: Toronto
Weight: 3.75 LBS
Adding to cart… The item has been added
  • WDM (Wave Division Multiplexing) technology allows the use of a single fiber cable for full-duplex bi-directional communication
  • Kit includes local and remote converter module for a complete solution
  • Supports standalone operation, or installation into the ETCHS2U Rackmount Chassis
  • Maximum Fiber Cable Length of 20 Km
  • Advanced features include Link-loss forwarding, remote status monitoring, two frame lengths
  • Supports full or half-duplex operation
    Marketing Information:

    The ET90110WDM2 10/100 Mbps Ethernet Single Mode WDM Fiber Media Converter Kit SC (20km) lets you extend a 10/100 Mbps Ethernet connection over single mode fiber, at distances up to 20 km (12.4 mi).
    The converter offers Wavelength-Division Multiplexing (WDM), enabling bi-directional communication over a single strand of fiber, essentially doubling the capacity of your existing fiber infrastructure without having to install new cabling.
    The Ethernet to WDM Fiber Kit includes both endpoints (two interchangeable modules) - a simple solution for connecting 10/100Base-T networks to remote locations using SC-terminated single mode fiber. The Ethernet to Fiber Converter also features a durable all-steel chassis, and a simple plug-and-play installation with minimal configuration required.
    For added versatility, this fiber media converter supports standalone operation, or one or both sides can be installed into a 20 Slot, 2U Rackmount Chassis (ETCHS2U).
    Backed by a StarTech.com 2-year warranty and free lifetime technical support.


    Total Number of Ports: 2
    Network (RJ-45): Yes
    DVI: No
    USB: No
    Management Port: No
    Number of Network (RJ-45) Ports: 1
    Number of SC Ports: 1
    Media Type Supported:
    • Twisted Pair
    • Optical Fiber

    Fiber Mode Supported: Single-mode
    Maximum Distance Supported: 12.4 Mile
    Ethernet Technology: Fast Ethernet
    Network Technology:
    • 10/100Base-TX
    • 100Base-FX

    Form Factor:
    • Rack-mountable
    • Desktop

    Height: 1" (25.40 mm)
    Width: 3.50" (88.90 mm)
    Depth: 6.30" (160.02 mm)
    Weight (Approximate): 1.22 kg
    Package Contents:
    • 1 x Local Media Converter Unit
    • 1 x Remote Media Converter Unit
    • 2 x Universal Power Adapters (NA/EU/UK/AU)
    • 1 x Grounding Screw
    • 1 x Instruction Manual

    Environmentally Friendly: Yes
    Environmental Certification:
    • RoHS
    • REACH
    • WEEE

    TAA Compliant: Yes
    Limited Warranty: 2 Year

[custom-specifications]

Specifications
Manufacturer: StarTech.com
Manufacturer Part Number: ET90110WDM2
Manufacturer Website Address: http://www.startech.com
Brand Name: StarTech.com
Product Name: 10/100 Mbps Ethernet Single Mode WDM Fiber Media Converter Kit SC 20km
Product Type: Transceiver/Media Converter
Interfaces/Ports
Total Number of Ports: 2
Network (RJ-45): Yes
DVI: No
USB: No
Management Port: No
Number of Network (RJ-45) Ports: 1
Number of SC Ports: 1
Media & Performance
Media Type Supported:
  • Twisted Pair
  • Optical Fiber

Fiber Mode Supported: Single-mode
Maximum Distance Supported: 12.4 Mile
Network & Communication
Ethernet Technology: Fast Ethernet
Network Technology:
  • 10/100Base-TX
  • 100Base-FX

Physical Characteristics
Form Factor:
  • Rack-mountable
  • Desktop

Height: 1" (25.40 mm)
Width: 3.50" (88.90 mm)
Depth: 6.30" (160.02 mm)
Weight (Approximate): 1.22 kg
Miscellaneous
Package Contents:
  • 1 x Local Media Converter Unit
  • 1 x Remote Media Converter Unit
  • 2 x Universal Power Adapters (NA/EU/UK/AU)
  • 1 x Grounding Screw
  • 1 x Instruction Manual

Environmentally Friendly: Yes
Environmental Certification:
  • RoHS
  • REACH
  • WEEE

TAA Compliant: Yes
Warranty
Limited Warranty: 2 Year

[/custom-specifications]

[custom-options]





[/custom-options]

2 Year
