StarTech.com 10G Network Card - 2 port - NBASE-T - RJ45 Port - Intel X550 chipset - Ethernet Card - Intel NIC Card - Add two 10 ports (ST20000SPEXI)

(No reviews) Write a Review
$526.44
SKU: ST20000SPEXI
UPC: 65030860598
Availability: Toronto
Weight: 1.00 LBS

Pre-order! 🗨️📞

  • Add two 100/1000/10Gbase-T RJ45 ports, providing cost-effective network connectivity for high bandwidth workstations and servers
  • Intel X540 chipset with Intel? Virtualization Technology for Connectivity
  • Up to 20Gbps (full duplex) bandwidth per port
  • Compliant with PCI Express Rev2.0 specification, using PCIe x8 (or higher) slot
  • PXE network boot support
  • Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
  • Support for 802.3ad Link Aggregation
  • Auto-MDIX support
  • Autonegotiation support
  • Up to 15K jumbo frame support
    Marketing Information: Now, you can add 10 GbE networking, while minimizing your deployment costs. This 10Gbase-T network card (NIC) lets you add two RJ45 ports through a single PCI Express slot, to deliver reliable high-speed network connections to your workstations and servers without draining your budget.

    Versatile and cost effective

    Compatible with a broad range of operating systems, this versatile dual-port NIC is ideal for many business applications that require upgrades to servers or workstations. It's a cost-effective way to enhance your server or computer capabilities by adding two powerful 10-Gigabit Ethernet ports, with support for advanced features such as VLAN tagging, jumbo frames, and Auto-MDIX.

    Reliable, high-performance connectivity

    This 2-port PCI Express 10GBase-T network card features the Intel® X540 chipset, designed to deliver the power, performance and enhanced capabilities you need for reliable network connections to your server or computer. The X540 chipset provides many advanced features including Intel® Virtualization Technology for connectivity and PXE network boot support.

    Compliant with IEEE 802.3/u/ab standards, the network card delivers a dependable way to upgrade or replace your existing network ports with dual 100/1000/10G compatible RJ45 ports, providing throughput capability of up 10Gbps in each direction (20Gbps total). It connects through a single, four-lane (x8 or higher) PCI Express slot.

    Easy installation

    With a dual-profile design, the PCI Express network card installs easily into a wide range of computer/server chassis, regardless of form factor. The card comes equipped for installation in a full-sized chassis, and includes a low-profile/half-height installation bracket that you can use as needed.

    The ST20000SPEXI is backed by a StarTech.com 2-year warranty and free lifetime technical support.

    More from the Manufacturer


    Chipset Manufacturer: Intel
    Chipset Model: X540
    Host Interface: PCI Express x4
    Total Number of Ports: 2
    Number of Network (RJ-45) Ports: 2
    Media Type Supported: Twisted Pair
    Data Transfer Rate: 2.50 GB/s
    Network Technology: 10GBase-T
    Product Color: Black
    Form Factor: Plug-in Card
    Height: 4.70" (119.38 mm)
    Width: 0.80" (20.32 mm)
    Depth: 6.40" (162.56 mm)
    Weight (Approximate): 155.9 g
    Package Contents:
    • 2-Port PCI Express 10GBase-T Ethernet Network Card - with Intel X540 Chip
    • 1 x low-profile Bracket
    • 1 x Instruction Manual

    Device Supported: Server
    Environmentally Friendly: Yes
    Country of Origin: China

[custom-specifications]

Specifications
Manufacturer: StarTech.com
Manufacturer Part Number: ST20000SPEXI
Manufacturer Website Address: http://www.startech.com
Brand Name: StarTech.com
Product Name: 2-Port PCI Express 10GBase-T Ethernet Network Card - with Intel X540 Chip
Packaged Quantity: 1
Product Type: 10Gigabit Ethernet Card
Technical Information
Chipset Manufacturer: Intel
Chipset Model: X540
Interfaces/Ports
Host Interface: PCI Express x4
Total Number of Ports: 2
Number of Network (RJ-45) Ports: 2
Media & Performance
Media Type Supported: Twisted Pair
Data Transfer Rate: 2.50 GB/s
Network & Communication
Network Technology: 10GBase-T
Physical Characteristics
Product Color: Black
Form Factor: Plug-in Card
Height: 4.70" (119.38 mm)
Width: 0.80" (20.32 mm)
Depth: 6.40" (162.56 mm)
Weight (Approximate): 155.9 g
Miscellaneous
Package Contents:
  • 2-Port PCI Express 10GBase-T Ethernet Network Card - with Intel X540 Chip
  • 1 x low-profile Bracket
  • 1 x Instruction Manual

Device Supported: Server
Environmentally Friendly: Yes
Country of Origin: China

[/custom-specifications]

2 Year
