StarTech.com 2 Port PCI Express SATA 6 Gbps eSATA Controller Card - Dual Port PCIe SATA III Card - 2 Int/2 Ext - 2 x 7-pin Female ATA (PEXESAT322I)

(No reviews) Write a Review
$67.99
$67.90
SKU: PEXESAT322I
UPC: 65030848428
Availability: Toronto
Weight: 1.00 LBS
Adding to cart… The item has been added
  • Includes both a full and low profile/half-height bracket for installation into any size of desktop computer
  • This versatile add-in card offers SATA III connectivity (6Gbps), while remaining backward compatible with SATA I (1.5Gbps) and II (3Gbps) device connections, which helps eliminate the expense of having to upgrade drives
  • This PCIe SATA controller card has two SATA channels that can be independently switched between the internal or external (eSATA) ports as needed
    Marketing Information:

    The PEXESAT322I PCI Express SATA III Controller Card (6 Gbps) gives you the option to add 2 internal or external SATA ports to your computer, through a single PCI Express (x1) card slot. The card features on board jumper selection, which enables you to configure the card to provide 2 internal or external SATA III ports, or one of each, as needed.
    The SATA III card features Port Multiplier (PM) support on each port, which allows multiple drives to be connected over a single cable when necessary to maximize the number of SATA device connections while reducing the amount of cabling required.
    The card is fully compliant with the SATA revision 3.0 specification (up to 6Gbps of data bandwidth), enabling you to utilize the speeds of high performance hard drives and Solid State Drives (SSD), as well as SATA-based optical drives (CD-ROM, DVD-ROM, Blu-Ray).
    The PEXESAT322I SATA III Controller card is backed by our 2-year manufacturer warranty and free lifetime technical support.


    Host Interface: PCI Express x1
    Controller Type: Serial ATA/600
    Total Number of SATA Ports: 4
    Number of SATA Ports (Internal): 2
    Number of SATA Ports (External): 2
    Height: 2.60" (66.04 mm)
    Width: 4.80" (121.92 mm)
    Thickness: 0.8"
    Form Factor: Plug-in Card
    Weight (Approximate): 59.5 g
    Package Contents:
    • PCIe SATA Controller
    • Low Profile Bracket
    • Driver CD
    • Instruction Manual

    Platform Supported: PC
    Environmentally Friendly: Yes
    Environmental Certification:
    • REACH
    • WEEE
    • RoHS

    Limited Warranty: 2 Year

[custom-specifications]

Specifications
Manufacturer: StarTech.com
Manufacturer Part Number: PEXESAT322I
Manufacturer Website Address: http://www.startech.com
Brand Name: StarTech.com
Product Name: PCIe SATA Controller
Packaged Quantity: 1
Product Type: SATA Controller
Technical Information
Host Interface: PCI Express x1
Controller Type: Serial ATA/600
Interfaces/Ports
Total Number of SATA Ports: 4
Number of SATA Ports (Internal): 2
Number of SATA Ports (External): 2
Physical Characteristics
Height: 2.60" (66.04 mm)
Width: 4.80" (121.92 mm)
Thickness: 0.8"
Form Factor: Plug-in Card
Weight (Approximate): 59.5 g
Miscellaneous
Package Contents:
  • PCIe SATA Controller
  • Low Profile Bracket
  • Driver CD
  • Instruction Manual

Platform Supported: PC
Environmentally Friendly: Yes
Environmental Certification:
  • REACH
  • WEEE
  • RoHS

Warranty
Limited Warranty: 2 Year
