StarTech.com 2 Port PCI RS422/485 Serial Adapter Card with 161050 UART - 2 x 9-pin DB-9 Male RS-422/485 Serial Universal PCI (PCI2S4851050)

Marketing Information:

The PCI2S4851050 2-Port PCI Serial Adapter Card (RS422/RS485) with 161050 UART adds two DB9 RS422/RS485 serial ports, using a single PCI expansion slot.

The PCI serial card offers a high performance 16C1050 UART and supports both 2-wire and 4-wire RS485 modes. The card delivers an efficient single-chip design and a large 256-byte transit/receive FIFO buffer that work together to provide high-speed serial communication while reducing the overall load on the system CPU.

With the included standard and low profile/half-height brackets, this PCI serial expansion card suits a broad range of system form factors, and is a perfect addition for connecting RS422/485 serial devices to a host computer. For added versatility, the RS422/RS485 adapter is able to accommodate 3.3 or 5V PCI/PCI-X slots.

Backed by a StarTech.com lifetime warranty and free lifetime technical support.

More from the Manufacturer

Host Interface: Universal PCI

Platform Supported: PC

UART Type: 161050

Number of Serial Ports (External): 2

Form Factor: Plug-in Card

Card Height: Dual-profile

Height: 1.80" (45.72 mm)

Width: 0.60" (15.24 mm)

Weight (Approximate): 56.7 g

Package Contents:

• 2 Port PCI RS422/485 Serial Adapter Card with 161050 UART
• Standard and Low Profile/half-height Brackets
• Driver CD

Environmentally Friendly: Yes

Country of Origin: Taiwan

TAA Compliant: Yes

Limited Warranty: Lifetime
