StarTech.com 8 Port POE Managed Ethernet Switch - 30W per PoE+ port - Industrial - Wall Mount - Managed Network Switch - 8 Ports - - - (IES81GPOEW)

Marketing Information: Easily deploy or scale your network with this Gigabit Ethernet switch, by adding eight copper Gigabit Ethernet (GbE) connections, including four PoE+ ports. This IP30 industrial network switch provides intelligent Layer 2 management. Its rugged, compact design and wall-mount option with front access make it ideal for demanding applications, even where space is limited.Expand your network

This Gigabit Ethernet switch lets you expand your network by connecting up to eight RJ45 devices (four PoE+). The 8-port switch enables up to eight users to share files and devices, such as printers and scanners, over a LAN connection, by enhancing your existing network capacity with additional ports.

The switch gives you the freedom to place your equipment in locations where power outlets are not available, with support for Power over Ethernet Plus. The network switch provides abundant PoE power, with up to 30 watts for each PoE port (120W budget).

With its compact design, you can wall-mount the Gigabit switch to provide convenient front access to ports and indicators. It's ideal for a wide range of applications, including tight installation areas with significant electromagnetic interference, such as control cabinets and panels. The network switch is also DIN-rail mountable.

The switch delivers efficient and stable performance, with Layer 2 management capabilities. This lets you control packet traffic on a busy network, and customize your settings to achieve optimal network performance, offering improved efficiency and reliability.

This rugged network switch features an IP30-rated metal housing and extended operating temperature range of -40°C to 75°C, which makes it ideal for a wide range of conditions. The sturdy metal enclosure offers durability, even in harsh industrial environments.

With support for 10/100/1000Mbps transfer speeds, this managed switch supports full/half-duplex auto-negotiation, jumbo frames, and auto MDI/MDIX operation. This lets you connect your network devices quickly and easily, with little to no configuration required.

To help prevent any unnecessary downtime, the switch features redundant 12-58V DC terminal block power inputs, which ensures seamless operation in the event of power dips or failures.

The IES81GPOEW is backed by a StarTech.com 2-year warranty and free lifetime technical support.

More from the Manufacturer

Total Number of Network Ports: 8

Network (RJ-45): Yes

Port/Expansion Slot Details: 4 x Gigabit Ethernet PoE+,4 x Gigabit Ethernet Network

Media Type Supported: Twisted Pair

Ethernet Technology: Gigabit Ethernet

Network Technology: 10/100/1000Base-T

Layer Supported: 2

Networking Standards: IEEE 802.3ad,IEEE 802.1D,IEEE 802.1w,IEEE 802.1s,IEEE 802.1p,IEEE 802.1Q,IEEE 802.1x,IEEE 802.1ab

Manageable: Yes

PoE (RJ-45) Port: Yes

Product Material: Steel

Form Factor: Wall Mountable,Rail-mountable,Magnetic Mount

Height: 1" (25.40 mm)

Width: 5.80" (147.32 mm)

Length: 5.30" (134.62 mm)

Weight (Approximate): 649.2 g

Package Contents:

• 8-Port (4 PoE+) Gigabit Ethernet Switch - Managed - Wall Mount with Front Access
• 1 x Terminal block Connector
• 4 x Screw Anchors
• 4 x Screws
• 4 x Attaching Pins
• 4 x Locking Pins
• 4 x Washers
• 4 x Magnets
• 1 x DIN Rail
• 3 x DIN Rail Screws
• 8 x RJ45 Dust Caps
• 1 x Quick Start Guide

Environmentally Friendly: Yes

Environmental Compliance: Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE)

Country of Origin: Taiwan

TAA Compliant: Yes

Limited Warranty: 2 Year
