StarTech.com Dual-Bay 2.5in SATA SSD / HDD Rack for 3.5in Front Bay - Trayless SATA Backplane - RAID - Easily connect and hot swap two (HSB225S3R)

Have questions?

  • Canadian distributor

    Proud Canadian business since 2007

  • IT experts available

    Consulting & Technicial services

  • Pre-configuration services

    From VoiP phone to Clustered servers

  • Delivering across Canada

    Shipping UPS Fedex & Purolator

Write a Review
MSRP: $94.99
$94.99
$91.58
You save $3.41
SKU: HSB225S3R
UPC: 65030872454
Availability: Stock In Canada - Ship UPS & Purolator
Weight: 1.00 LBS
Shipping: Calculated at Checkout
Adding to cart… The item has been added

    Marketing Information:

    This HDD rack lets you install two 2.5" SATA hard drives or solid-state drives into a single 3.5" front bay. With configurable RAID support, the SATA drive rack provides an ideal data storagesolution.

    Flexible storage solution

    Configure and arrange your drives for increased drive capacity, or add data redundancy, with built-in hardware RAID functionality. The HDD rack offers software and operating system independent operations and with multiple RAID options, such as RAID 0, RAID 1, spanning, or JBOD, you can build the data storage solution that works best for you.

    Hot swap your SATA drives

    This SATA backplane is trayless and hot-swappable, which makes it easy to install and remove your drives from your computer system when required, without having to open the case every time. It also provides a more convenient way to create backupsfor data recovery and archiving.

    Designed for durability and trouble-free use

    The removable hard-drive bay/backplane features durable aluminum construction for long-lasting performance. The SATA backplane also has LED indicators for power and hard drive activity, and drive status, which makes it easy to monitor the status of your hard drives and RAID array.

    The HSB225S3R is backed by a StarTech.com 2-year warranty and free lifetime technical support.

    Number of Hard Drives Supported: 2

    Number of Hard Drives Installed: No

    Number of Solid State Drive Supported: 2

    Number of Solid State Drive Installed: No

    Number of Total Expansion Bays: 2

    Number of 2.5" Bays: 2

    Controller Type: Serial ATA/600

    RAID Supported: Yes

    RAID Levels: 0, 1, Concatenation, JBOD

    Host Interface: SATA/600

    Height: 1" (25.40 mm)

    Width: 4" (101.60 mm)

    Depth: 5.50" (139.70 mm)

    Form Factor: Internal

    Weight (Approximate): 7.76 oz (220 g)

    Package Contents:

    • Dual-Bay 2.5" SATA SSD / HDD Rack for 3.5" Bay - Trayless - RAID
    • 1 x SATA Data Cable
    • 1 x SATA to LP4 Adapter
    • 1 x Installation Screw Kit
    • 1 x Quick Start Guide

    Country of Origin: China

    Environmentally Friendly: Yes

    Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE),Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)

    Limited Warranty: 2 Year

[custom-highlights]
  • SATA III (6Gbps) drive interface, compatible with SATA I, II and III
  • Increase drive capacity, performance, or data redundancy, with multiple RAID modes: RAID 0, RAID 1, spanning
  • Supports up to two 2.5" SATA SSD/HDDs
  • Front-mount bay design for installation into any standard 3.5" front bay
  • Trayless design, with hot-swappable bays, makes it easy to swap drives in and out of the mobile rack
  • Well-built, durable aluminum construction
  • LED indicators for power and activity, to easily monitor your hard drives
  • 50,000 insertion rating
  • Single SATA data and power connection
[/custom-highlights]

[custom-specifications]

Specifications
ManufacturerStarTech.com
Manufacturer Part NumberHSB225S3R
Manufacturer Website Addresshttp://www.startech.com
Brand NameStarTech.com
Product NameDual-Bay 2.5" SATA SSD / HDD Rack for 3.5" Bay - Trayless - RAID
Packaged Quantity1
Product TypeDAS Storage System
Storage
Number of Hard Drives Supported2
Number of Hard Drives InstalledNo
Number of Solid State Drive Supported2
Number of Solid State Drive InstalledNo
I/O Expansions
Number of Total Expansion Bays2
Number of 2.5" Bays2
Controllers
Controller TypeSerial ATA/600
RAID SupportedYes
RAID Levels0, 1, Concatenation, JBOD
Interfaces/Ports
Host InterfaceSATA/600
Physical Characteristics
Height1" (25.40 mm)
Width4" (101.60 mm)
Depth5.50" (139.70 mm)
Form FactorInternal
Weight (Approximate)7.76 oz (220 g)
Miscellaneous
Package Contents
  • Dual-Bay 2.5" SATA SSD / HDD Rack for 3.5" Bay - Trayless - RAID
  • 1 x SATA Data Cable
  • 1 x SATA to LP4 Adapter
  • 1 x Installation Screw Kit
  • 1 x Quick Start Guide
Country of OriginChina
Environmentally FriendlyYes
Environmental ComplianceWaste Electrical and Electronic Equipment Directive (WEEE),Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Warranty
Limited Warranty2 Year

[/custom-specifications]

[custom-options]











[/custom-options]

[custom-user-manual]

Available Documentation:


User-Manual
Manufacturer-Brochure

[/custom-user-manual]

Warranty Infomartion

2 Year
