StarTech.com Gigabit Fiber to RJ45 Ethernet Media Converter Dongle, PoE Powered, SMF/MMF, Single/Multimode Optical Fiber, Metal - PoE (D01ML55P-FIBER-MEDIA)
Write a Review
StarTech.com
StarTech.com Gigabit Fiber to RJ45 Ethernet Media Converter Dongle, PoE Powered, SMF/MMF, Single/Multimode Optical Fiber, Metal - PoE (D01ML55P-FIBER-MEDIA)
-
Business Pricing
Volume deals available
-
IT Experts
Consulting & support
-
Config Service
From PC to server
-
Canada Stocked
Toronto - Alberta - BC
- Whether you are a lefty or a righty, the symmetrically shaped mouse suits both
- USB Type A connectivity for a easy connection
- Optical LED for smoother movement and hassle-free performance
- Transceiver/Media Converter
- 1 x Quick-Start Guide
Total Number of Ports: 2
Network (RJ-45): Yes
USB: Yes
Number of PoE (RJ-45) Ports: 1
PoE Port Type: PD
Number of LC Ports: 1
LC Port Type: Duplex
Media Type Supported: Twisted Pair,Optical Fiber
Fiber Mode Supported: Single-mode,Multi-mode
Fiber Optic Cable Wavelength: 1310 nm
Maximum Data Transfer Rate: 1 Gbit/s
Maximum Distance Supported: 10 km (6.21 Mile)
Ethernet Technology: Gigabit Ethernet
Network Technology: 1000Base-T,1000Base-LX
Power Source: PoE
Power Consumption: 2.50 W
Form Factor: Compact
Height: 0.70" (17.78 mm)
Width: 3.20" (81.28 mm)
Weight (Approximate): 1.50 oz (42.52 g)
Package Contents:
Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)
TAA Compliant: Yes
Limited Warranty: 2 Year
- FIBER TO ETHERNET MEDIA CONVERTER: Converts Gigabit fiber to RJ45 copper in a compact form factor; No SFP/Cat6 cables required; Conveniently PoE powered (802.3af or higher); Dimensions: 3.2x0.8x0.7in (82.4x20x17.2mm)
- APPLICATIONS: Upgrade PoE capable computers, switches, routers, or other equipment to fiber; Suitable for on-site network troubleshooting, field deployments, industrial automation, telecommunications, broadcasting, data centers, and remote networking
- SHORT & LONG RANGE FIBER: LC slot compatible w/Single-Mode (10km) & Multi-Mode (800m); Single speed 1Gbps for both fiber and RJ-45 ports; Status LEDs including LFPT (Link Fault Pass-Through) enables IT admins to monitor network connectivity
- DURABLE CONSTRUCTION: IP20-rated full-metal housing for enhanced durability; Metal RJ45 latch tab ensures a robust and secure connection; Spring-loaded dust cover protects port when not in use
- TECH SPECS: Single speed 1Gbps; x1 LC port; x1 RJ45; LC duplex; Singlemode SMF (10km) & multimode MMF (800m); 1310nm; LFPT; IP20 rated all metal housing; PoE powered 30-57V input; Max power consumption 2.5W
[custom-specifications]
| Specifications | |
| Manufacturer | StarTech.com |
| Manufacturer Part Number | D01ML55P-FIBER-MEDIA |
| Manufacturer Website Address | http://www.startech.com |
| Brand Name | StarTech.com |
| Product Name | Transceiver/Media Converter |
| Packaged Quantity | 1 |
| Product Type | Transceiver/Media Converter |
| Interfaces/Ports | |
| Total Number of Ports | 2 |
| Network (RJ-45) | Yes |
| USB | Yes |
| Number of PoE (RJ-45) Ports | 1 |
| PoE Port Type | PD |
| Number of LC Ports | 1 |
| LC Port Type | Duplex |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Fiber Mode Supported | Single-mode,Multi-mode |
| Fiber Optic Cable Wavelength | 1310 nm |
| Maximum Data Transfer Rate | 1 Gbit/s |
| Maximum Distance Supported | 10 km (6.21 Mile) |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-T,1000Base-LX |
| Power Description | |
| Power Source | PoE |
| Power Consumption | 2.50 W |
| Physical Characteristics | |
| Form Factor | Compact |
| Height | 0.70" (17.78 mm) |
| Width | 3.20" (81.28 mm) |
| Weight (Approximate) | 1.50 oz (42.52 g) |
| Miscellaneous | |
| Package Contents |
|
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 2 Year |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Additional-pdf1
[/custom-user-manual]
Warranty Information
2 Year
