StarTech.com HDMI Video and USB over IP Distribution Kit with Video Wall Support - 1080p - Deploy HDMI and USB content for digital a - (ST12MHDLANU)
Have questions?
1-844-836-8268
Ask an Experts-
Canadian distributor
Proud Canadian business since 2007
-
IT experts available
Consulting & Technicial services
-
Pre-configuration services
From VoiP phone to Clustered servers
-
Delivering across Canada
Shipping UPS Fedex & Purolator
- 1 x HDMI over IP transmitter
- 1 x HDMI over IP receiver
- 2 x power adapters
- 2 x screws
- 1 x screw driver
- 2 x CAT5 cables
- 2 x mounting brackets
- 1 x quick install guide
Marketing Information:
This HDMI® over IP kit lets you extend an HDMI signal, as well as four USB peripheral device connections, over your network. You can use additional receivers (sold separately) to distribute the HDMI and USB signals to multiple locations and combine your remote displays to create a video wall while using the USB connection to extend a touch screen to create an interactive digital signage presentation.
Versatile configuration options
In a point-to-multipoint setup, you can connect the HDMI over IP kit through an unmanaged or managed Gigabit LAN portal. You can also connect one or several sources (transmitters) to multiple displays (receivers) over your network, using a managed Gigabit Ethernet switch with IGMP. For further scalability, you can combine up to 16 different extender kits.
For smaller-scale applications, you can use the extender kit as a point-to-point video extender by connecting the transmitter and receiver units directly over Cat5 or Cat6 cabling for a one-to-one HDMI extension up to 330 feet (100 meters).
Manage your video distribution from your mobile device
This HDMI distribution kit features an easy-to-use video control software app that helps you manage your IP video distribution. The app is simple to set up, with automatic hardware detection, and it lets you switch video sources for each remote display. You can also create and manage a video wall, for an impressive digital signage presentation that's sure to catch your audience's attention.
The software is available on iOS for your iPhone or iPad, and Android™ for your smartphone or tablet.
Professional, cost-effective, simple installation
The HDMI over IP extender kit can be powered using Power over Ethernet to conveniently connect both data and power using an 802.3af PoE switch or injector, avoiding the hassle of external power adapters.
The kit includes optional mounting hardware for a tidy installation. Ideal for high-definition applications, the extender supports 1080p video resolutions and digital stereo audio. Plus, because the extender uses standard non-proprietary Cat5e or Cat6 Ethernet cable with RJ45 connectors, it eliminates both the expense and hassle of running specialized cables.
The extender also features an EDID copy function, which ensures native resolution and maximum compatibility with your display or projector, for a convenient plug-and-play installation.
Download the StarTech.com Video Control software to manage your IP video distribution.
Note: For best performance, a managed network switch with IGMP is recommended if you are using more than one transmitter, or more than four receivers, Non-managed network switches may also limit the performance of other devices connected to the same network.
The ST12MHDLANU is TAA compliant and backed by a StarTech.com 2-year warranty with free lifetime technical support.
Connectivity Technology: Wired
Number of Input Devices Supported: 1
Number of Output Devices Supported: 1
Maximum Operating Distance: 330 ft (100584 mm)
Graphics Modes: WUXGA
Maximum Video Resolution: 1920 x 1200
Network (RJ-45): Yes
HDMI In: Yes
HDMI Out: Yes
USB: Yes
Number of Network (RJ-45) Ports: 2
Number of USB Ports: 5
Number of HDMI Inputs: 1
Number of HDMI Outputs: 1
Media Type Supported: Twisted Pair
Twisted Pair Cable Standard: Category 6
Product Color: Black
Transmitter Height: 1.10" (27.94 mm)
Transmitter Width: 5.20" (132.08 mm)
Transmitter Depth: 5.20" (132.08 mm)
Receiver Height: 1.10" (27.94 mm)
Receiver Width: 5.20" (132.08 mm)
Receiver Depth: 5.20" (132.08 mm)
Transmitter Weight (Approximate): 1.20 kg
Receiver Weight (Approximate): 1.20 kg
Package Contents:
TAA Compliant: Yes
Environmentally Friendly: Yes
Limited Warranty: 2 Year
- Versatile video distribution with support for large multi-display presentations, video walls, video switching and point-to-point extension
- Extends four USB peripheral devices for remote console control
- Free mobile app makes it easy to manage switching video wall control (iOS / Android / Chrome browser)
- Tidy, professional installation using the included mounting hardware
- Connect using a Gigabit LAN network
- Easy point-to-point or point-to-multipoint setup
- Extend HDMI using existing network infrastructure
- Supports video resolutions up to 1920x1080 (1080p)
- Can be powered by PoE (Power over Ethernet) or by included power adapter for versatile installation
[custom-specifications]
Specifications | |
Manufacturer | StarTech.com |
Manufacturer Part Number | ST12MHDLANU |
Manufacturer Website Address | http://www.startech.com |
Brand Name | StarTech.com |
Product Name | HDMI and USB over IP Distribution Kit - 1080p |
Packaged Quantity Condition | Kit |
Product Type | Video Extender Transmitter/Receiver |
Technical Information | |
Connectivity Technology | Wired |
Number of Input Devices Supported | 1 |
Number of Output Devices Supported | 1 |
Maximum Operating Distance | 330 ft (100584 mm) |
Video | |
Graphics Modes | WUXGA |
Maximum Video Resolution | 1920 x 1200 |
Interfaces/Ports | |
Network (RJ-45) | Yes |
HDMI In | Yes |
HDMI Out | Yes |
USB | Yes |
Number of Network (RJ-45) Ports | 2 |
Number of USB Ports | 5 |
Number of HDMI Inputs | 1 |
Number of HDMI Outputs | 1 |
Media & Performance | |
Media Type Supported | Twisted Pair |
Twisted Pair Cable Standard | Category 6 |
Physical Characteristics | |
Product Color | Black |
Transmitter Height | 1.10" (27.94 mm) |
Transmitter Width | 5.20" (132.08 mm) |
Transmitter Depth | 5.20" (132.08 mm) |
Receiver Height | 1.10" (27.94 mm) |
Receiver Width | 5.20" (132.08 mm) |
Receiver Depth | 5.20" (132.08 mm) |
Transmitter Weight (Approximate) | 1.20 kg |
Receiver Weight (Approximate) | 1.20 kg |
Miscellaneous | |
Package Contents |
|
TAA Compliant | Yes |
Environmentally Friendly | Yes |
Warranty | |
Limited Warranty | 2 Year |
[/custom-specifications]
[custom-options]




[/custom-options]
[custom-user-manual]
Available Documentation:
User-Manual
Manufacturer-Brochure
Additional-pdf1
Additional-pdf2
[/custom-user-manual]
Warranty Infomartion
2 Year
