StarTech.com Rackmount KVM Console - 8 Port with 17-inch LCD Monitor - VGA KVM - Cables and Mounting Hardware Included - Connect up to (RKCONS1708K)
Have questions?
1-844-836-8268
Ask an Experts-
Canadian distributor
Proud Canadian business since 2007
-
IT experts available
Consulting & Technicial services
-
Pre-configuration services
From VoiP phone to Clustered servers
-
Delivering across Canada
Shipping UPS Fedex & Purolator
Free Shipping*
Shipping Restrictions
Additional fees may apply for shipments to locations beyond normal service areas and heavy weight or oversize items.
Free Shipping*
Shipping Restrictions
Additional fees may apply for shipments to locations beyond normal service areas and heavy weight or oversize items.
- 8 VGA KVM Cables
- Mounting Rails
- M5 Cage Nuts and Screws
- 8-Port Rackmount KVM Console with 17" Display
- 8 x KVM Cables
- 8 x M5 Cage Nuts
- 8 x M5 Screws
- 5 x Power Cords (NA, JP, UK, EU, ANZ)
- 2 x Mounting Rails
- 1 x Quick-Start Guide
Marketing Information:
Providing centralized control of up to eight servers, this 8-port rackmount KVM console gives you easy access to your systems. With a minimal footprint, it mounts in a server rack or cabinet using only 1U of rack space.
An All-Inclusive Solution
The 1U rackmount console features a built-in keyboard, a touchpad for intuitive control, and a 17-inch LCD display that supports resolutions up to 1280x1024.
This 8-port KVM console comes with everything you need to set up right out of the box:
Simple System Integration
With direct access to eight systems or servers, the 8-port KVM module gives you the flexibility you need to easily integrate the console into your existing server infrastructure.
StarTech.com Rack Consoles
Rack consoles provide convenient, rack-mounted control options for single servers or the entire server room. KVM consoles include LCD display, keyboard, and trackpad, all sliding into 1U of rack space. The RKCONS1708K is backed by a StarTech.com 2-year warranty and free lifetime technical support
KVM Switch: Yes
Number of Computers Supported: 8
Device Type: LCD Rack Console
Screen Size: 17"
Display Screen Type: LCD
Screen Mode: SXGA
Screen Resolution: 1280 x 1024
Keyboard: Yes
Pointing Device Type: TouchPad
PS/2 Port: Yes
USB: Yes
VGA: Yes
Number of PS/2 Ports: 2
Number of USB Ports: 2
Number of VGA Ports: 1
Number of Proprietary Ports: 8
Input Voltage: 120 V AC,230 V AC
Input Voltage Range: 100V AC to 240V AC
Power Consumption: 13 W
Product Color: Black
Product Material: Steel
Rack Height: 1U
Height: 1.70" (43.18 mm)
Width: 17.60" (447.04 mm)
Depth: 20.70" (525.78 mm)
Weight (Approximate): 13.34 kg
Package Contents:
Platform Supported: PC
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin: China
Limited Warranty: 2 Year
- TECH SPECIFICATIONS: Rackmount KVM Console, 17" Active Matrix TFT LCD Monitor, 1280 x 1024, 8 port VGA KVM switch w/ 6 ft. cables, 99 key full keyboard + numeric keypad & trackpad; Supports USB 2.0
- PROFESSIONAL & SECURE: Customizable hot-keys, on-screen display (OSD), multi-level user security, user access levels / port permissions, & auto scan
- INTEGRATED DESIGN: Combines a KVM + Console w/ integrated power supply into 1U of rack space allowing space for other equipment. Mount depth: 22" [56 cm] to 35" [90 cm] (incl. mounting hardware)
- HEAVY DUTY: LCD KVM drawer has durable steel construction and heavy duty rail design that supports frequent use in operating environments from 0C to 40C (32F to 104F) with an MTBF of 50,000 hours
- TESTED & PROVEN: This OS independent rack console is universally compatible w/ leading servers and backed by a StarTech.com 2-year warranty and free lifetime 24/5 multilingual technical support
[custom-specifications]
Specifications | |
---|---|
Manufacturer | StarTech.com |
Manufacturer Part Number | RKCONS1708K |
Manufacturer Website Address | http://www.startech.com |
Brand Name | StarTech.com |
Product Name | 8-Port Rackmount KVM Console with 17" Display |
Product Type | LCD Rack Console | Technical Information |
KVM Switch | Yes |
Number of Computers Supported | 8 |
Device Type | LCD Rack Console | Display & Graphics |
Screen Size | 17" |
Display Screen Type | LCD |
Screen Mode | SXGA |
Screen Resolution | 1280 x 1024 | Input Devices |
Keyboard | Yes |
Pointing Device Type | TouchPad | Interfaces/Ports |
PS/2 Port | Yes |
USB | Yes |
VGA | Yes |
Number of PS/2 Ports | 2 |
Number of USB Ports | 2 |
Number of VGA Ports | 1 |
Number of Proprietary Ports | 8 | Power Description |
Input Voltage | 120 V AC,230 V AC |
Input Voltage Range | 100V AC to 240V AC |
Power Consumption | 13 W | Physical Characteristics |
Product Color | Black |
Product Material | Steel |
Rack Height | 1U |
Height | 1.70" (43.18 mm) |
Width | 17.60" (447.04 mm) |
Depth | 20.70" (525.78 mm) |
Weight (Approximate) | 13.34 kg | Miscellaneous |
Package Contents |
|
Platform Supported | PC |
Environmentally Friendly | Yes |
Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
Country of Origin | China | Warranty |
Limited Warranty | 2 Year |
[/custom-specifications]
[custom-options]




[/custom-options]
[custom-user-manual]
Available Documentation:
User-Manual
Manufacturer-Brochure
Additional-pdf1
Additional-pdf2
[/custom-user-manual]
Warranty Infomartion
2 Year
