- 8× 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
- Green Ethernet technology saves power consumption
- IEEE 802.3x flow control provides reliable data transfer
- Steel housing, desktop or wall-mounting design
- Support 802.1p/DSCP QoS and IGMP Snooping function
- Plug and play, no configuration needed
- Monitor and address loop-related issues within your network structure to prevent disruptions caused by looping
Features: FanlessTotal Number of Network Ports: 8Network (RJ-45): YesPort/Expansion Slot Details: 8 x Gigabit Ethernet NetworkMedia Type Supported: Twisted PairEthernet Technology: Gigabit EthernetNetwork Technology: 10/100/1000Base-TLayer Supported: 2Networking Standards: - IEEE 802.3i
- IEEE 802.3u
- IEEE 802.3ab
- IEEE 802.3x
- IEEE 802.1p
Manageable: NoInput Voltage: 5 V DCPower Source: Power Consumption: 3.92 WProduct Material: MetalForm Factor: Height: 1" (25.40 mm)Width: 6.20" (157.48 mm)Depth: 4" (101.60 mm)Package Contents: - Omada 8-Port Gigabit Desktop Switch
- Power Adapter
- Installation Guide
Environmentally Friendly: YesEnvironmental Compliance: Restriction of Hazardous Substances (RoHS)
[custom-specifications]
SpecificationsManufacturer: TP-LINK Technologies Co., Ltd
Manufacturer Part Number: DS108G
Manufacturer Website Address: http://www.tp-link.com
Brand Name: TP-Link
Product Line: Omada
Product Model: DS108G
Product Name: DS105G Omada 8-Port Gigabit Desktop Switch
Product Type: Ethernet Switch
Technical InformationFeatures: Fanless
Interfaces/PortsTotal Number of Network Ports: 8
Network (RJ-45): Yes
Port/Expansion Slot Details: 8 x Gigabit Ethernet Network
Media & PerformanceMedia Type Supported: Twisted Pair
Ethernet Technology: Gigabit Ethernet
Network Technology: 10/100/1000Base-T
Network & CommunicationLayer Supported: 2
Networking Standards:
- IEEE 802.3i
- IEEE 802.3u
- IEEE 802.3ab
- IEEE 802.3x
- IEEE 802.1p
Management & ProtocolsManageable: No
Power DescriptionInput Voltage: 5 V DC
Power Source:
Power Consumption: 3.92 W
Physical CharacteristicsProduct Material: Metal
Form Factor:
Height: 1" (25.40 mm)
Width: 6.20" (157.48 mm)
Depth: 4" (101.60 mm)
MiscellaneousPackage Contents:
- Omada 8-Port Gigabit Desktop Switch
- Power Adapter
- Installation Guide
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
[/custom-specifications]
