Tripp Lite by Eaton 4-Port Dual Monitor DVI KVM Switch with Audio and USB 2.0 Hub, Cables included - 4 Computer(s) - 1 Local User(s) - (B004-2DUA4-K)

Marketing Information: Tripp Lite's B004-2DUA4-K 4-Port Dual Monitor KVM switch allows for the control of four computers with Dual Head DVI video cards via a single set of keyboard, mouse, and dual displays. Built-in USB 2.0 and 3.5 mm. Mini Stereo ports provide added functionality, allowing you to share USB peripherals (flash drive, web cam, powered USB hub, etc.), Speakers (2.1 stereo sound), and Microphone amongst the connected computers. Switch between the connected computers using the front panel pushbuttons, keyboard hotkey commands, or a function that allows for switching via the scroll wheel on your mouse. Switch the KVM, USB, and Audio functionality all at the same time, or separately. KVM control can be fixed on one
computer, while the USB 2.0 hub and/or Audio functionality is fixed on another. And set-up is quick and simple, with no software to install, and KVM cables included, so you're ready to go right out of the box.

The B004-2DUA4-K is the perfect solution for CAD/CAM and Graphic designers; Medical, Educational and Financial institutions; and High-End gaming. Its DVI-I connectors support both Dual Link digital resolutions up to 2560 x 1600, and analog resolutions up to 2048 x 1536. Connect a VGA monitor or computer port by using a P556-Series DVI to VGA adapter cable instead of the included DVI-D cables. Regardless of whether you use DVI or VGA, the KVM stores the EDID (Extended Display Identification Data) of the connected monitors, which ensures optimal display resolution and prevents any delay or change in video resolution when switching between or booting computers. This full time DDC support provides the
necessary EDID information for optimal performance on Windows 7 and other operating systems. Additionally, if you have the need for more than two monitors, the KVM's Quad-View Mode allows for computers with three- or four-head video cards to share KVM, audio and USB peripherals by connecting two Dual Display/Monitor KVM switches together.

More from the Manufacturer

Number of Computers Supported: 4

Number of Local Users Supported: 1

Graphic Mode: WQXGA

Maximum Video Resolution: 2560 x 1600

Network (RJ-45): Yes

USB: Yes

DVI: Yes

Number of Network (RJ-45) Ports: 1

Number of USB Ports: 7

Number of DVI Ports: 10

Form Factor: Desktop

Height: 1.75" (44.45 mm)

Width: 17" (431.80 mm)

Depth: 6" (152.40 mm)

Weight (Approximate): 5.11 lb (2317.86 g)

Package Contents:

• 4-Port Dual Monitor DVI KVM Switch with Audio and USB 2.0 Hub
• 4 x 6 ft. DVI-D Dual Link / USB KVM Cable Kits
• 4 x 6 ft. DVI-D Dual Link Cables
• External Power Supply (Input: 100-240V, 50/60Hz, 0.5A Output: 5.3V, 2.4A)
• Owner's Manual

Environmentally Friendly: Yes

Environmental Compliance: Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Restriction of Hazardous Substances (RoHS)

Country of Origin: Taiwan

TAA Compliant: Yes

Limited Warranty: 3 Year
