Tripp Lite by Eaton PDUMV15-72 36-Outlets PDU - Metered - NEMA 5-15P - 36 x NEMA 5-15R - 120 V AC - 15 ft Cord Length - 0U - Vertical (PDUMV15-72)

Marketing Information:

Single-Phase 0U PDU Distributes and Monitors Network-Grade Power in Real Time

This metered PDU provides real-time local reporting of the total load level via its built-in digital current metering. Ideal for network IT applications, small computer rooms and other equipment rack applications, the PDUMV15-72 features 36 NEMA 5-15R 120V outlets for connecting equipment. An included 15-foot cord with NEMA 5-15P input plug connects to a distant AC power source, generator or protected UPS system to distribute power to connected loads.

Digital Load Meter Helps Prevent Potentially Expensive Overloads

A digital ammeter reports the total load for all connected equipment. Monitoring amperage helps ensure load levels remain well below maximum capacity with no danger of overload that could lead to costly downtime or damaged equipment. Maintaining proper load levels, even while adding new equipment, can keep your TCO (total cost of ownership) low.

Up-to-Date Safety Features Protect Your Vital Equipment

A lighted on/off switch is protected by an integrated transparent plastic cover to help prevent an accidental shutdown that could lead to costly downtime. A 15A circuit breaker protects connected components from dangerous overloads.

Versatile Installation Options Give You Plenty of Choices

The 72-inch 0U all-metal housing mounts vertically in an EIA-standard 19-inch rack using the included toolless mounting buttons or the included mounting clips and hardware. You may also use the clips to secure the PDU to a wall, counter or other flat, secure surface. Bolt-down retention brackets keep power cords organized and your rack free of clutter.

PDU Type: Metered

Phase: Single Phase

Plug/Connector Type: NEMA 5-15P

Receptacle Type: NEMA 5-15R

Receptacle Detail: 36 x NEMA 5-15R

Protection Type: Overload Protection,Accidental Power Shutdown

Input Voltage: 120 V AC

Output Voltage: 100 V AC,120 V AC,127 V AC

Power Rating (Watt): 1.44 kW

Input Current: 15 A

Mounting Orientation: Vertical

Placement: Under-counter

Rack Height: 0U

Cord Length: 15 ft

Height: 72.47" (1840.74 mm)

Width: 1.64" (41.66 mm)

Depth: 1.50" (38.10 mm)

Weight (Approximate): 2.79 kg

Package Contents:

• PDUMV15-72 36-Outlets PDU
• Plug Retention Brackets With Installation Hardware
• Rack-mounting Hardware
• Owner's Manual

Country of Origin: China

Environmentally Friendly: Yes

Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Limited Warranty: 2 Year
