Tripp Lite SmartRack 6U Low-Profile Switch-Depth-Plus Wall-Mount Rack Enclosure Cabinet - For Server - 6U Rack Height x 19" (482.60 x (SRW6UDP)

Write a Review
$325.35
$530.64
$318.84
(You save $6.51 )
SKU: SRW6UDP
UPC: 037332191458
Availability: Toronto
Weight: 48.50 LBS
Shipping: Calculated at Checkout
Adding to cart… The item has been added
  • Maximum load capacity of 200 lb.
  • Locking steel cabinet vented at sides, front, top and bottom
  • Flow-through ventilation keeps equipment cool
  • Secures 6U of 19 in. rack equipment up to 20.5 in. deep
  • Mounts to wall or rolls on floor(with optional SRCASTER)
    Marketing Information: The SRW6UDP SmartRack 6U Low-Profile Switch-Depth-Plus Wall-Mount Rack Enclosure Cabinet is designed to house EIA-standard 19-inch rack equipment in network wiring closets, retail locations, classrooms, back offices and other areas with limited floor space where you need equipment to be secure, organized and out of the way. Constructed from heavy-duty steel with a durable black powder-coated finish, the cabinet has a maximum load capacity of 200 pounds.

    The side panels and front door lock securely to help prevent damage, tampering or theft. The front, top, bottom and removable side panels are vented, which allows air to flow freely and keep equipment cool. The reversible front door can open left or right by rotating the cabinet 180° before mounting. Convenient top and bottom ports allow easy cable routing.

    The SRW6UDP comes fully assembled and ready to mount to the wall, or use Tripp Lite's optional SRCASTER rolling caster kit to make it a mobile rack. Square and threaded mounting holes and numbered rack spaces make equipment installation easy. The vertical mounting rails adjust in 7/8-inch increments to accommodate equipment up to 20.5 inches deep, such as network switches and patch panels.
    Application/Usage: Server
    Form Factor: Wall Mountable
    Product Color: Black
    Product Material: Steel
    Maximum Weight Capacity: 90.72 kg
    Static/Stationary Weight Capacity: 41.14 kg
    Height: 14.57" (370.10 mm)
    Width: 23.62" (599.90 mm)
    Depth: 21.71" (551.40 mm)
    Rack Height: 6U
    Rack Width: 19" (482.60 mm)
    Rack Depth: 20.50" (520.70 mm)
    Weight (Approximate): 20.50 kg
    Package Contents:
    • SmartRack 6U Low-Profile Switch-Depth-Plus Wall-Mount Rack Enclosure Cabinet
    • 12 x M6 Screws
    • 12 x M6 Cage Nuts
    • 12 x M6 Cup Washers
    • 12 x 12-24 Screws
    • Removable Mounting Plate
    • 3 x Mounting Plate Screws
    • 2 x Keys
    • Owner's Manual

    Assembly Required: No
    Environmentally Friendly: Yes
    Country of Origin: China
    Limited Warranty: 5 Year

[custom-specifications]

Specifications
Manufacturer: Tripp Lite by Eaton
Manufacturer Part Number: SRW6UDP
Manufacturer Website Address: https://tripplite.eaton.com/
Brand Name: Tripp Lite
Product Line: SmartRack
Product Model: SRW6UDP
Product Name: SmartRack 6U Low-Profile Switch-Depth-Plus Wall-Mount Rack Enclosure Cabinet
Product Type: Rack Cabinet
Technical Information
Application/Usage: Server
Physical Characteristics
Form Factor: Wall Mountable
Product Color: Black
Product Material: Steel
Maximum Weight Capacity: 90.72 kg
Static/Stationary Weight Capacity: 41.14 kg
Height: 14.57" (370.10 mm)
Width: 23.62" (599.90 mm)
Depth: 21.71" (551.40 mm)
Rack Height: 6U
Rack Width: 19" (482.60 mm)
Rack Depth: 20.50" (520.70 mm)
Weight (Approximate): 20.50 kg
Miscellaneous
Package Contents:
  • SmartRack 6U Low-Profile Switch-Depth-Plus Wall-Mount Rack Enclosure Cabinet
  • 12 x M6 Screws
  • 12 x M6 Cage Nuts
  • 12 x M6 Cup Washers
  • 12 x 12-24 Screws
  • Removable Mounting Plate
  • 3 x Mounting Plate Screws
  • 2 x Keys
  • Owner's Manual

Assembly Required: No
Environmentally Friendly: Yes
Country of Origin: China
Warranty
Limited Warranty: 5 Year
