TUF NVIDIA GeForce RTX 4070 Graphic Card - 12 GB GDDR6X - 7680 x 4320 - 2.58 GHz Boost Clock - 192 bit Bus Width - PCI Express 4.0 - - (TUF-RTX4070-O12G-GAMING)

Marketing Information:

SUS TUF Gaming GeForce RTX™ 4070 12GB GDDR6X OC Edition with DLSS 3, lower temps, and enhanced durability

• Powered by NVIDIA DLSS3, ultra-efficient Ada Lovelace arch, and full ray tracing.
• 4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering
• 3rd Generation RT Cores: Up to 2x ray tracing performance
• OC mode: 2580 MHz (OC mode)/ 2550 MHz (Default mode)
• Axial-tech fans scaled up for 21% more airflow
• Dual ball fan bearings last up to twice as long as conventional designs
• Military-grade capacitors rated for 20K hours at 105C make the GPU power rail more durable
• Vented exoskeleton adds structural rigidity and vents to increase heat reliability
• Auto-Extreme precision automated manufacturing for higher reliability
• GPU Tweak III software provides intuitive performance tweaking, thermal controls, and system monitoring

ARMED FOR FLOW

NVIDIA Ada Lovelace architecture elevated by buffed cooling and power delivery, and backed with an arsenal of rugged reinforcements to cover your six. Lock, load, and dominate with the TUF Gaming GeForce RTX™ 4070.

AXIAL-TECH UPGRADES Air Superiority

Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 21% more air through the card, setting the stage for lower temperatures, less noise, and higher performance.

NEW DIRECTION Well-maintained Formation

The two side fans spin counterclockwise to minimize turbulence and maximize air dispersion through the heatsink. All three fans come to a standstill when GPU temps are below 50 Celsius, letting you play less-demanding games or perform light tasks in relative silence. Fans start up again when temps are over 55 Celsius, referencing a speed curve that balances performance and acoustics for work or play.

3.15-SLOT DESIGN Phase That Blaze

A generously oversized heatsink combo efficiently soak up heat from the GeForce RTX 4070 GPU so that it can be whisked away by the three Axial-tech fans.

MILITARY-GRADE 20K CAPACITORS Resilient Squadron

A lineup of capacitors rated to last 20,000 hours at 105 Celsius brings higher temperature and ripple tolerance to the GPU power rail, arming the card for long-term deployment in challenging conditions.

VENTED EXOSKELETON Stay Frosty

The backplate is made of sturdy aluminium to brace the PCB and sink heat away from onboard components.

Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.

API Supported: OpenGL 4.6

Number of Monitors Supported: 4

Maximum Digital Display Resolution: 7680 x 4320

CUDA Cores: 5888

Features: Triple-fan Cooler

Chipset Manufacturer: NVIDIA

Chipset Line: GeForce

Chipset Series: RTX

Chipset Model: RTX 4070

GPU Boost Clock: 2.58 GHz

Standard Memory: 12 GB

Memory Technology: GDDR6X

Bus Width: 192 bit

Host Interface: PCI Express 4.0

DisplayPort: Yes

Number of DisplayPort Outputs: 3

HDMI: Yes

Number of HDMI Outputs: 1

Power Supply Wattage: 650 W

Power Connector: 1x 8-pin

Slot Space Required: Triple

Form Factor: Plug-in Card

Cooler Type: Fan Cooler

Height: 2.48" (63 mm)

Width: 5.47" (139 mm)

Length: 11.85" (301 mm)

Package Contents:

• Gaming GeForce RTX 4070 12GB GDDR6X OC Edition Graphic Card
• 1 x Collection Card
• 1 x Speedsetup Manual
• 1 x Thank you Card
• 1 x TUF Velcro Hook & Loop
• 1 x TUF Graphics card holder
• 1 x TUF Gaming Certificate

Platform Supported: PC

Environmentally Friendly: Yes

Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Limited Warranty: 36 Month
