Ubiquiti Rocket Prism AC Gen2 Wireless Bridge - 500 Mbit/s, 5 GHz, Gigabit Ethernet (RP-5AC-GEN2)

Marketing Information: airMAX® ac BaseStation with airPrism® Technology

The Rocket® Prism 5AC covers the full 5 GHz radio band and incorporates both airMAX ac and airPrism technologies for maximum performance of wireless links in high-density areas.

Management Wi-Fi Radio

The Rocket® Prism 5AC integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.

Improved Surge Protection

The Rocket® Prism 5AC features enhanced protection against ESD events.

Revolutionary Filtering Technology

Ubiquiti's patented airPrism technology provides breakthrough radio selectivity in unlicensed wireless band performance. airPrism technology isolates signals within the operating channel to increase capacity and throughput in co-location deployments.

Designed for High Performance

The Rocket® Prism 5AC features EMI-shielded metal housing, GPS, airPrism circuitry, and the airView® real-time spectrum analyzer to deliver maximum spectral efficiency/throughput.

Full-Band 5 GHz Coverage

The Rocket® Prism 5AC delivers complete coverage of the 5 GHz spectrum with a single radio.

Now with airOS®8

airOS®8 provides powerful features, including airMAX® ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.

Wireless LAN Standard: IEEE 802.11ac

Frequency Band: 5 GHz

Wireless Transmission Speed: 500 Mbit/s

Ethernet Technology: Gigabit Ethernet

Number of Network (RJ-45) Ports: 1

PoE (RJ-45) Port: No

PoE PD Port: Yes

VGA: No

HDMI: No

USB: No

Powerline: No

Management Port: No

Height: 9.06" (230 mm)

Width: 1.57" (40 mm)

Depth: 3.46" (88 mm)

Weight (Approximate): 400 g

Environmentally Friendly: Yes

Environmental Compliance: Restriction of Hazardous Substances (RoHS)
