- Delivers maximum remote power to IP cameras & POE devices
- 802.3bt compliant and GigE compatible
- 90W Power output
- Safety assured as POE is only enabled to compliant devices
- Integrated overload protection
- Compact, wall-mountable unit
- Sealed, fanless design for reliability
- CE
- FCC
- EN 55032 Class B
- EN55024
- VCCI
- UL/EN/IEC 60950-1 (Ed2)
Marketing Information: OUTSOURCE 90 delivers the highest power allowed by the POE standard (802.3bt), used for external PTZ IP cameras and other very high-power applications.
Protection Type: Overload Protection
Input Voltage: 120 V AC,230 V AC
Maximum Output Voltage: 54 V DC
Maximum Output Power: 90 W
Input Ports: 10/100/1000Base-T,IEC 60320 C14
Output Ports: 10/100/1000Base-T
Form Factor: Wall Mountable
Height: 1.73" (44 mm)
Width: 3.50" (89 mm)
Length: 6.57" (167 mm)
Weight (Approximate): 475 g
Certifications & Standards:
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Country of Origin: China
[custom-specifications]
Specifications | |
Manufacturer | Veracity USA, Inc |
Manufacturer Part Number | VOR-OS-90-US |
Manufacturer Website Address | http://www.veracityusa.com |
Brand Name | Veracity |
Product Line | OUTSOURCE 90 |
Product Name | OUTSOURCE 90 PoE Injector |
Product Type | PoE Injector |
Technical Information | |
Protection Type | Overload Protection |
Power Description | |
Input Voltage | 120 V AC,230 V AC |
Maximum Output Voltage | 54 V DC |
Maximum Output Power | 90 W |
Interfaces/Ports | |
Input Ports | 10/100/1000Base-T,IEC 60320 C14 |
Output Ports | 10/100/1000Base-T |
Physical Characteristics | |
Form Factor | Wall Mountable |
Height | 1.73" (44 mm) |
Width | 3.50" (89 mm) |
Length | 6.57" (167 mm) |
Weight (Approximate) | 475 g |
Miscellaneous | |
Certifications & Standards |
|
Environmentally Friendly | Yes |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Country of Origin | China |
