APC Basic Rack 14.4kW 40A PDU - 6 x IEC 320-C19 - 14.4kW - 1U Rack-mountable (AP7516)
Write a Review
APC by Schneider Electric
APC Basic Rack 14.4kW 40A PDU - 6 x IEC 320-C19 - 14.4kW - 1U Rack-mountable (AP7516)
-
Business Pricing
Volume deals available
-
IT Experts
Consulting & support
-
Config Service
From PC to server
-
Canada Stocked
Toronto - Alberta - BC
- Whether you are a lefty or a righty, the symmetrically shaped mouse suits both
- USB Type A connectivity for a easy connection
- Optical LED for smoother movement and hassle-free performance
- Basic Rack 14.4kW 40A PDU
- Installation guide
- Rack mounting brackets
PDU Type: Basic
Plug/Connector Type: Hubbell CS8365C
Receptacle Type: IEC 60320 C19
Receptacle Detail: 6 x IEC 60320 C19
Protection Type: Overload Protection
Input Voltage: 208 V
Output Voltage: 200 V AC,208 V AC
Power Rating (Watt): 14.40 kW
Mounting Orientation: Horizontal
Mount Type: Rack-mountable
Placement: Front,Rear
Rack Height: 1U
Cord Length: 8 ft (2.44 m)
Height: 1.73" (44 mm)
Width: 17.20" (437 mm)
Depth: 10" (254 mm)
Weight (Approximate): 17.59 lb (7978.69 g)
Package Contents:
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Limited Warranty: 2 Year
Additional Warranty Information: 2 years repair or replace
- Provide circuit protection and easy configuration for trouble-free access
- Basic PDU is the space-saving and cost-effective way to deliver power
[custom-specifications]
| Specifications | |
| Manufacturer | Schneider Electric SA |
| Manufacturer Part Number | AP7516 |
| Manufacturer Website Address | http://www.schneider-electric.com |
| Brand Name | APC by Schneider Electric |
| Product Line | Basic Rack |
| Product Name | Basic Rack 14.4kW 40A PDU |
| Product Type | PDU |
| Technical Information | |
| PDU Type | Basic |
| Plug/Connector Type | Hubbell CS8365C |
| Receptacle Type | IEC 60320 C19 |
| Receptacle Detail | 6 x IEC 60320 C19 |
| Protection Type | Overload Protection |
| Power Description | |
| Input Voltage | 208 V |
| Output Voltage | 200 V AC,208 V AC |
| Power Rating (Watt) | 14.40 kW |
| Physical Characteristics | |
| Mounting Orientation | Horizontal |
| Mount Type | Rack-mountable |
| Placement | Front,Rear |
| Rack Height | 1U |
| Cord Length | 8 ft (2.44 m) |
| Height | 1.73" (44 mm) |
| Width | 17.20" (437 mm) |
| Depth | 10" (254 mm) |
| Weight (Approximate) | 17.59 lb (7978.69 g) |
| Miscellaneous | |
| Package Contents | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 2 Year |
| Additional Warranty Information | 2 years repair or replace |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Additional-pdf1
[/custom-user-manual]
Warranty Information
2 Year
