- PDU provides active metering enabling energy optimization and circuit protection
- With basic PDU it becomes the easiest way to distribute facility UPS or generator power to multiple rack loads
Marketing Information: Reliable rack power distributionPDU Type: BasicPlug/Connector Type: NEMA L5-30PReceptacle Type: NEMA 5-20RReceptacle Detail: 24 x NEMA 5-20RInput Voltage: Output Voltage: 120 V ACPower Rating (VA): 2.88 kVAProduct Color: BlackMount Type: Rack-mountableRack Height: 0UCord Length: 10 ftHeight: 63.74" (1619 mm)Width: 2.20" (56 mm)Depth: 1.73" (44 mm)Weight (Approximate): 5.57 kgPackage Contents: - Basic Rack 2880VA PDU
- Installation guide
- Rack mounting brackets
- Toolless mounting kit
Environmentally Friendly: YesEnvironmental Compliance: Restriction of Hazardous Substances (RoHS)Limited Warranty: 2 YearAdditional Warranty Information: 2 years repair or replace
[custom-specifications]
SpecificationsManufacturer: Schneider Electric SA
Manufacturer Part Number: AP7532
Manufacturer Website Address: http://www.schneider-electric.com
Brand Name: APC by Schneider Electric
Product Line: Basic Rack
Product Name: Basic Rack 2880VA PDU
Packaged Quantity: 1 Each
Product Type: PDU
Technical InformationPDU Type: Basic
Plug/Connector Type: NEMA L5-30P
Receptacle Type: NEMA 5-20R
Receptacle Detail: 24 x NEMA 5-20R
Power DescriptionInput Voltage:
Output Voltage: 120 V AC
Power Rating (VA): 2.88 kVA
Physical CharacteristicsProduct Color: Black
Mount Type: Rack-mountable
Rack Height: 0U
Cord Length: 10 ft
Height: 63.74" (1619 mm)
Width: 2.20" (56 mm)
Depth: 1.73" (44 mm)
Weight (Approximate): 5.57 kg
MiscellaneousPackage Contents:
Basic Rack 2880VA PDU Installation guideRack mounting bracketsToolless mounting kitEnvironmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
WarrantyLimited Warranty: 2 Year
Additional Warranty Information: 2 years repair or replace
