ASUS GEFORCE ROG-STRIX-RTX4060TI-O8G-GMNG OC 8GB GDDR6 128 BIT (ROG-STRIX-RTX4060TI-O8G-GAMING)

Marketing Information:

The Ultimate Platform for Gamers and Creators

Powered by GeForce RTX 40 Series and DLSS 3

New Streaming Multiprocessors

• Up to 2x performance and power efficiency

Fourth-Gen Tensor Cores

• Up to 4x performance with DLSS 3 vs. brute-force rendering

Third-Gen RT Cores

• Up to 2x ray tracing performance

Axial-tech Upgrades | A Fresh Spin

Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 21% more air through the card, setting the stage for lower temperatures, less noise, and higher performance

Reverse Rotation and 0dB Technology | Orchestrated Chill

The two side fans spin counterclockwise to minimize turbulence and maximize air dispersion through the heatsink. All three fans come to a standstill when GPU temps are below 50 Celsius, letting you play less-demanding games or perform light tasks in relative silence. Fans start up again when temps are over 55 C, referencing a speed curve that balances performance and acoustics for work or play.

3.1-slot Design | Through Thick and Fin

The custom sink is generously sized and structured to soak up heat from the GeForce RTX 4060 Ti GPU so that it can be efficiently whisked away by the three Axial-tech fans.

Premium Power Delivery | 1st Responder

Digital power control, an array of high-current power stages, and a lineup of 15K caps ensure massive reserves to reliably push performance boundaries

Compact PCB | Packs a Punch

Component and trace layouts have been optimized onto a short PCB to reduce power losses

VENTED EXOSKELETON | Stay Frosty

The backplate is made of sturdy aluminium to brace the PCB and sink heat away from onboard components

FanConnect II | Hook up

Two PWM FanConnect headers provide additional DIY flexibility. Chassis fans can be directly attached to the card and tuned with a curve that is based on CPU and GPU temperatures, delivering extra intake or exhaust for demanding 3D tasks.

Reinforcements | Additional Perks

The rear I/O bracket is made from stainless steel to prevent corrosion in humid climates and provide a more resilient mount. A conveniently placed Dual Bios switch allows quick selection between "performance" and "quiet" speed profiles for the Axial-tech fans

Power Sensing | Quick Diagnosis

Know if your PSU is worthy. ROG Strix GeForce RTX 4060 Ti graphics cards feature a high-speed circuit that constantly monitors input power from the PSU and utilizes conveniently placed LEDs to indicate voltage regulation issues and cable connection problems.

Auto-Extreme Technology | Reliability Boost

Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall

API Supported: OpenGL 4.6

Number of Monitors Supported: 4

Maximum Digital Display Resolution: 7680 x 4320

CUDA Cores: 4352

Features: Triple-fan Cooler

AI-powered: Yes

Chipset Manufacturer: NVIDIA

Chipset Line: GeForce

Chipset Series: RTX

Chipset Model: RTX 4060 Ti

GPU Boost Clock: 2.72 GHz

Standard Memory: 8 GB

Memory Technology: GDDR6

Bus Width: 128 bit

Host Interface: PCI Express 4.0

DisplayPort: Yes

Number of DisplayPort Outputs: 3

HDMI: Yes

Number of HDMI Outputs: 1

Power Supply Wattage: 650 W

Power Connector: 1x 8-pin

Slot Space Required: Triple

Form Factor: Plug-in Card

Cooler Type: Fan Cooler

Height: 2.44" (61.90 mm)

Width: 5.26" (133.50 mm)

Length: 12.26" (311.40 mm)

Package Contents:

• Strix GeForce RTX 4060 Ti 8GB GDDR6 OC Edition Graphic Card
• 1 x Collection Card
• 1 x Speedsetup Manual
• 1 x Thank you Card
• 1 x ROG Graphics card holder
• 1 x ROG Velcro Hook & Loop

Platform Supported: PC

Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Limited Warranty: 36 Month
