Asus NUC 13 Pro NUC13ANKi5 Barebone System - Core i5 13th Gen i5-1340P Dodeca-core (12 Core) - Intel Chip - 64 GB DDR4 SDRAM Maximum - (90AR0031-M00080)
Have questions?
1-844-836-8268
Ask an Experts-
Canadian distributor
Proud Canadian business since 2007
-
IT experts available
Consulting & Technicial services
-
Pre-configuration services
From VoiP phone to Clustered servers
-
Delivering across Canada
Shipping UPS Fedex & Purolator
Free Shipping*
Shipping Restrictions
Additional fees may apply for shipments to locations beyond normal service areas and heavy weight or oversize items.
Free Shipping*
Shipping Restrictions
Additional fees may apply for shipments to locations beyond normal service areas and heavy weight or oversize items.
- NUC 13 Pro NUC13ANKi5 Barebone System
- VESA Bracket
Marketing Information:
Business Driver. Space Saver.
NUC 13 Pro Mini PCs, Kits, and Boards offer the combination of size, performance, and reliability you need to drive modern business.
It all starts with 13th Gen Intel Core processors that deliver outsized performance in a 4x4 form factor, with up to 14 processor cores (6P+8E) and up to 64GB dual-channel DDR4 memory. Select SKUs also come with Intel vPro®Enterprise, which provides comprehensive security, enterprise-grade stability, and hardware-based remote management.
The NUC Pro Software Suite (NPSS) helps to ensure digital signage applications keep running during any unexpected system failures. Businesses also benefit from advanced features including power control, hardware alarm clock, hardware KVM, boot redirection, beyond firewall support, cloud-based manageability, remote PC remedy, and unattended system control.
To provide an eco-friendly foundation for businesses, NUC 13 Pro Mini PCs and Kits are upgradable, reparable, and reusable. Every system is qualified for 24x7 operation.
Processor Type: Core i5
Processor Generation: 13th Gen
Processor Model: i5-1340P
Processor Core: Dodeca-core (12 Core)
Maximum Turbo Speed: 4.60 GHz
64-bit Processing: Yes
Chipset Manufacturer: Intel
Maximum Memory Supported: 64 GB
Memory Technology: DDR4 SDRAM
Memory Standard: DDR4-3200/PC4-25600
Intel Optane Memory Ready: No
Controller Type: NVMe,Serial ATA
Ethernet Technology: 2.5 Gigabit Ethernet
Wireless LAN: Yes
Wireless LAN Standard: IEEE 802.11ax
Bluetooth: Yes
Bluetooth Standard: Bluetooth 5.3
HDMI: Yes
Total Number of USB Ports: 7
Number of USB 3.2 Ports: 3
Number of Onboard USB 2.0 Ports: 3
Network (RJ-45): Yes
DisplayPort: Yes
Number of Thunderbolt 4 Ports: 2
Operating System Supported: Windows 11 Home,Windows 11 Pro,Windows 10 IoT Enterprise,Red Hat Linux,Ubuntu Linux
Height: 1.46" (37 mm)
Width: 4.41" (112 mm)
Depth: 4.61" (117 mm)
Package Contents:
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
- DDR4 SDRAM compatible slot - Installs memory that reduces processor's idle time and enhances computer's performance
- Can connect up to 7 USB peripherals
- NVMe interface provides quick data transfer and greater throughput
[custom-specifications]
Specifications | |
Manufacturer | ASUS Computer International |
Manufacturer Part Number | 90AR0031-M00080 |
Manufacturer Website Address | http://www.asus.com |
Brand Name | Asus |
Product Line | NUC 13 Pro |
Product Model | NUC13ANKi5 |
Product Name | NUC 13 Pro NUC13ANKi5 Barebone System |
Product Type | Barebone System |
Processor | |
Processor Type | Core i5 |
Processor Generation | 13th Gen |
Processor Model | i5-1340P |
Processor Core | Dodeca-core (12 Core) |
Maximum Turbo Speed | 4.60 GHz |
64-bit Processing | Yes |
Chipset | |
Chipset Manufacturer | Intel |
Memory | |
Maximum Memory Supported | 64 GB |
Memory Technology | DDR4 SDRAM |
Memory Standard | DDR4-3200/PC4-25600 |
Intel Optane Memory Ready | No |
Controllers | |
Controller Type | NVMe,Serial ATA |
Network & Communication | |
Ethernet Technology | 2.5 Gigabit Ethernet |
Wireless LAN | Yes |
Wireless LAN Standard | IEEE 802.11ax |
Bluetooth | Yes |
Bluetooth Standard | Bluetooth 5.3 |
Interfaces/Ports | |
HDMI | Yes |
Total Number of USB Ports | 7 |
Number of USB 3.2 Ports | 3 |
Number of Onboard USB 2.0 Ports | 3 |
Network (RJ-45) | Yes |
DisplayPort | Yes |
Number of Thunderbolt 4 Ports | 2 |
Operating System | |
Operating System Supported | Windows 11 Home,Windows 11 Pro,Windows 10 IoT Enterprise,Red Hat Linux,Ubuntu Linux |
Physical Characteristics | |
Height | 1.46" (37 mm) |
Width | 4.41" (112 mm) |
Depth | 4.61" (117 mm) |
Miscellaneous | |
Package Contents |
|
Environmentally Friendly | Yes |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
