Asus NVIDIA GeForce RTX 4070 Graphic Card - 12 GB GDDR6X - 7680 x 4320 - 2.55 GHz Boost Clock - 192 bit Bus Width - PCI Express 4.0 - (DUAL-RTX4070-O12G)

Marketing Information:

ASUS Dual GeForce RTX™ 4070 OC Edition 12GB GDDR6X with two powerful Axial-tech fans and a 2.56-slot design for broad compatibility

• Powered by NVIDIA DLSS3, ultra-efficient Ada Lovelace arch, and full ray tracing.
• 4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering
• 3rd Generation RT Cores: Up to 2x ray tracing performance
• OC edition: Boost Clock 2550 MHz (OC Mode)/2520 MHz (Default Mode)
• Axial-tech fan design: features a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure.
• A2.56-slot design maximizes compatibility and cooling efficiency for superior performance in small chassis.
• 0dB technology lets you enjoy light gaming in relative silence.
• Dual ball fan bearings can last up to twice as long as sleeve bearing designs.

2x Fans. 2x Fun.

ASUS Dual GeForce RTX™ 4070 fuses dynamic thermal performance with broad compatibility. Advanced cooling solutions from flagship graphics cards - including two Axial-tech fans for maximizing airflow to the heatsink - are packed into the 26.7 cm long, 2.56-slot card, delivering more power in less space. These enhancements make ASUS Dual the perfect choice for gamers who want heavyweight graphics performance in a compact build.

Powered by GeForce RTX 40 Series and DLSS 3

New Streaming Multiprocessors

• Up to 2x performance and power efficiency

Fourth-Gen Tensor Cores

• Up to 4x performance with DLSS 3
• vs. brute-force rendering

Third-Gen RT Cores

• Up to 2x ray tracing performance

Axial-tech Fan Design Better, faster, stronger

Two tried-and-true Axial-tech fans feature a smaller hub that facilitates longer blades and a barrier ring to increase downward air pressure.

Auto-Extreme Technology Precision automated manufacturing

Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.

GPU TWEAK III Monitor, tweak, and tune

The ASUS GPU Tweak III utility takes graphics card tuning to the next level. It allows you to tweak critical parameters including GPU core clocks, memory frequency, and voltage settings, with the option to monitor everything in real-time through a customizable on-screen display. Advanced fan control is also included along with many more features to help you get the most out of your graphics card.

API Supported: OpenGL 4.6

Number of Monitors Supported: 4

Maximum Digital Display Resolution: 7680 x 4320

CUDA Cores: 5888

Features: Dual-fan Cooler,VR Ready

Chipset Manufacturer: NVIDIA

Chipset Line: GeForce

Chipset Series: RTX

Chipset Model: RTX 4070

GPU Boost Clock: 2.55 GHz

Standard Memory: 12 GB

Memory Technology: GDDR6X

Bus Width: 192 bit

Host Interface: PCI Express 4.0

DisplayPort: Yes

Number of DisplayPort Outputs: 3

HDMI: Yes

Number of HDMI Outputs: 1

Power Supply Wattage: 650 W

Power Connector: 1x 8-pin

Slot Space Required: Triple

Form Factor: Plug-in Card

Cooler Type: Fan Cooler

Height: 2.01" (51.13 mm)

Width: 5.27" (133.94 mm)

Length: 10.51" (267.01 mm)

Platform Supported: PC
