- Works adequately in situations where the supply is prone to sags and surges
- 390 W load capacity - backup power for your valuable electronics
- Up to 2 minute runtime on full load to preserve critical data from power shortage interruptions
- 685 VA load capacity - work without any interruption during power outages
Marketing Information: The CyberPower CP685AVRG uninterruptible power supply (UPS) system provides battery backup and surge protection for lightning-induced surges and other power events that can damage electronic equipment. This UPS, with line-interactive topology, uses simulated sine wave output to deliver enough battery backup to power connected electronics through a utility power failure. The unit has enough runtime to perform a graceful shutdown to protect against the loss of data and damage to valuable desktop computers, workstations, networking devices, and home entertainment systems. The CP685AVRG uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power. AVR is essential in areas where power fluctuations occur frequently, and it helps to extend the unit's battery life. CyberPower designed the CP685AVRG to minimize noise for a quieter work environment and run efficiently to reduce power consumption.
- Experience higher efficiency with lower energy cost
- 685 VA load capacity - work without any interruption during power outages
- Prevent critical data loss by staying powered during a blackout with up to 390 W load capacity
- Up to 2 minute runtime on full load to preserve critical data from power shortage interruptions
More from the Manufacturer
Plug/Connector Type: NEMA 5-15PReceptacle Type: NEMA 5-15RReceptacle Detail: 8 x NEMA 5-15RTransfer Time: 4 msApplication/Usage: - Desktop Computer
- Network Device
- Home Theater
- Router
- Modem
- VoIP Phone System
- Workstation
Load Capacity (VA): 685 VALoad Capacity (Watt): 390 WInput Voltage: 120 V ACInput Voltage Range: 90 V AC - 140 V ACOutput Voltage: 120 V ACWaveform Type: Simulated Sine WaveNetwork (RJ-45): YesBackup/Run Time (Full Load): 2 MinuteTypical Battery Recharge Time: 8 HourHeight: 6.80" (172.72 mm)Width: 11" (279.40 mm)Depth: 3.50" (88.90 mm)Form Factor: CompactWeight (Approximate): 5.44 kgPackage Contents: - CP685AVRG AVR UPS Series
- User's Manual
- USB Device Cable
- PowerPanel Personal Software CD or Free Download Card
Energy Star: YesEnvironmentally Friendly: YesCountry of Origin: ChinaLimited Warranty: 3 Year
[custom-specifications]
SpecificationsManufacturer: CyberPower Systems, Inc
Manufacturer Part Number: CP685AVRG
Manufacturer Website Address: https://www.cyberpowersystems.com/
Brand Name: CyberPower
Product Series: AVR UPS
Product Model: CP685AVRG
Product Name: CP685AVRG AVR UPS Series
Product Type: Line-interactive UPS
Technical InformationPlug/Connector Type: NEMA 5-15P
Receptacle Type: NEMA 5-15R
Receptacle Detail: 8 x NEMA 5-15R
Transfer Time: 4 ms
Application/Usage:
- Desktop Computer
- Network Device
- Home Theater
- Router
- Modem
- VoIP Phone System
- Workstation
Power DescriptionLoad Capacity (VA): 685 VA
Load Capacity (Watt): 390 W
Input Voltage: 120 V AC
Input Voltage Range: 90 V AC - 140 V AC
Output Voltage: 120 V AC
Waveform Type: Simulated Sine Wave
Interfaces/PortsNetwork (RJ-45): Yes
Battery InformationBackup/Run Time (Full Load): 2 Minute
Typical Battery Recharge Time: 8 Hour
Physical CharacteristicsHeight: 6.80" (172.72 mm)
Width: 11" (279.40 mm)
Depth: 3.50" (88.90 mm)
Form Factor: Compact
Weight (Approximate): 5.44 kg
MiscellaneousPackage Contents:
- CP685AVRG AVR UPS Series
- User's Manual
- USB Device Cable
- PowerPanel Personal Software CD or Free Download Card
Energy Star: Yes
Environmentally Friendly: Yes
Country of Origin: China
WarrantyLimited Warranty: 3 Year
