CyberPower Smart App Intelligent LCD OR2200LCDRTXL2U 2190 VA Tower/Rack-mountable UPS - 2190VA/1650W - 6 Minute Full Load - 8 x NEMA - (OR2200LCDRTXL2U)

Marketing Information:

• A rack/tower convertible UPS with line interactive topology, the CyberPower Smart LCD OR2200LCDRTXL2U provides battery backup (using simulated sine wave output) and surge protection for department servers, workgroup servers, workstations, network devices, and telecom installations without active PFC power supplies. The OR2200LCDRTXL2U uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. This model accepts the RMCARD205 network management card for remote management and control via a standard web browser or network management system. The OR2200LCDRTXL2U comes with a three-year warranty and a

• 300,000 Connected Equipment Guarantee.
  Battery Backup
  Supplies power long enough for equipment to properly shut down when utility power fails. Helps prevent loss of data and minimizes the component stress caused by a hard shutdown.

  Surge Protection
  Diverts excess voltage away from sensitive electronic equipment during an AC power surge or power spike to prevent damage.

  Automatic Voltage Regulation (AVR)
  AVR increases the AC power and maintains a safe voltage level without switching to battery mode and conserving battery life.

  Multifunction LCD
  Displays immediate, detailed information on the UPS battery and power conditions, alerting users to potential problems before they can affect critical equipment and cause downtime. The rotatable panel is easily readable whether the UPS is rack mounted or standing as a tower.

  Data Line Protection
  Prevents power surges that travel through telephone, coaxial, and Ethernet lines from causing damage to electronics.

  PowerPanel® Business Software
  Provides IT professionals with tools for monitoring and managing the UPS and backup power. This software offers remote management functionality. Free software download available. See the Resources tab.

  Rack/Tower Versatility
  Allows for horizontal rack or vertical tower installation.

  GreenPower UPS™ Bypass Design
  Is a patented design that allows utility power to bypass the UPS transformer, when AC power is stable, which reduces energy consumption, noise, and heat buildup.

  Simulated Sine Wave Output
  Provides a manufactured waveform output to supply cost-effective battery backup power for equipment that does not require sine wave output.

  Line Interactive Topology
  Exists when a line interactive UPS has an autotransformer that regulates low voltages (e.g., brownouts) and over voltages (e.g., spikes) without having to switch to battery.

  Three-Year Warranty
  CyberPower will repair or replace a defective UPS system (including batteries) within three years of the purchase date. See warranty for details.

  Connected Equipment Guarantee
  CyberPower will repair or replace properly connected equipment if it is damaged by a power surge.

  What's In The Box

  UPS unit, User's manual, Rackmount brackets, Stands, Telephone cable, Emergency Power Off cable, USB A+B type cable.

  More from the Manufacturer

AVR: Yes

Plug/Connector Type: NEMA 5-20P

Receptacle Type: NEMA 5-20R

Receptacle Detail: 8 x NEMA 5-20R

Number of Battery & Surge Outlets: 8

Transfer Time: 4 ms

Dataline Protection: RJ-11,RG-6

Overload Protection: Yes

Energy Saving: GreenPower UPS™ Bypass Technology

Application/Usage: Workstation,Server,Network Device,Telecommunication

Load Capacity (VA): 2.19 kVA

Input Voltage: 120 V AC

Output Voltage: 120 V AC

Input Frequency: 63 Hz

Output Frequency: 60 Hz

Waveform Type: Simulated Sine Wave

Network Management: SNMP Manageable

Alarm: Battery Mode,Low Battery,Overload

Status Indicators:

• Power On
• Wiring Fault

Serial Port: Yes

USB (HID Compliant) Port: Yes

EPO Port: Yes

Number of Batteries: 4

Battery Characteristics: Maintenance-free

Battery Chemistry: Lead Acid

Battery Size: 12V

Battery Capacity: 9000 mAh

Backup/Run Time (Full Load): 6 Minute

Backup/Run Time (Half Load): 15 Minute

Typical Battery Recharge Time: 8 Hour

Replaceable Battery: Yes

Maximum Operating Temperature: 104°F (40°C)

Product Color: Black

Form Factor: Rack/Tower

Rack Height: 2U

Height: 3.50" (88.90 mm)

Width: 17" (431.80 mm)

Depth: 18.80" (477.52 mm)

Weight (Approximate): 40.82 kg

Package Contents:

• Smart App LCD OR2200LCDRTXL2U 2190 VA Tower/Rack-mountable UPS
• User's manual
• Rackmount brackets
• Stands, Telephone cable
• Emergency Power Off cable
• USB A+B type cable

Software Included: PowerPanel Business Edition Software

Energy Star: No

Country of Origin: Philippines

Environmentally Friendly: Yes

Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Limited Warranty: 3 Year
