- Prevent critical data loss by staying powered during a blackout with up to 1.50 kW load capacity
- Up to 6.50 minute runtime on full load to preserve critical data from power shortage interruptions
- 1.50 kVA load capacity - work without any interruption during power outages
Marketing Information: The PR1500RTXL2UCN is a Smart App Sinewave rack/tower convertible UPS with line-interactive topology, surge protection, and battery backup. CyberPower's Smart App Sinewave series has sine wave output to eliminate power gaps that can be detected by sensitive equipment and cause unexpected shutdowns.
The Smart App Sinewave PR1500RTXL2UCN improves battery life through battery equalization technology and Automatic Voltage Regulation (AVR), which corrects minor power fluctuations without switching to battery power. The enhanced chassis design with an easy-to-access toolless front panel, captive screws for battery panel access, and color-coded rear panel make battery changes and installations simple and fast. The PR1500RTXL2UCN also has an innovative LCD panel that rotates 90°, tilts for a better viewing angle, and provides information on 47 different settings including UPS stats, UPS setup and control management, and testing options.
This model accepts the BP48VP2U02 Extended Battery Module (EBM) for expanded runtime during power outages and includes pre-installed RMCARD205 network management card for remote management and control via a standard web browser or network management system. Includes built in cloud monitoring.
With a
- 400,000 connected equipment guarantee and a three-year warranty, you can trust CyberPower's commitment to the quality of the PR1500RTXL2UCN.
AVR: YesPlug/Connector Type: NEMA 5-15PReceptacle Type: NEMA 5-15RReceptacle Detail: 8 x NEMA 5-15RNumber of Battery & Surge Outlets: 8Number of Critical Load Outlets: 4Overload Protection: YesCord Length: 10 ftTransfer Time: 4 msEMI/RFI Noise Filter: YesLoad Capacity (VA): 1.50 kVALoad Capacity (Watt): 1.50 kWInput Voltage: 120 V ACInput Voltage Range: 70 V AC - 155 V ACOutput Voltage: - 100 V AC
- 110 V AC
- 120 V AC
- 125 V AC
Input Frequency: 63 HzOutput Frequency: 60 HzWaveform Type: Sine WaveSurge Energy Rating: 2430 JCircuit Breaker: YesOutput Power Factor: 1Display: LCDNetwork Management: - SNMP/HTTP Remote Monitoring
- Relay-MS Card
- Network Card
Alarm: Battery ModeStatus Indicators: LED Indicators:
Serial Port: YesUSB: YesEPO Port: YesUSB (HID Compliant) Port: YesNumber of Batteries: 4Battery Characteristics: SealedBattery Chemistry: Lead AcidBattery Size: 12VBattery Capacity: 9000 mAhBackup/Run Time (Full Load): 6.50 MinuteBackup/Run Time (Half Load): 17.90 MinuteHot Swappable: YesTypical Battery Recharge Time: 3 HourReplaceable Battery: YesMaximum Operating Elevation: 9842.52 ft (3000000 mm)Maximum Storage Elevation: 49209.32 ft (14999000 mm)Storage Temperature: 5°F (-15°C) - 113°F (45°C)Operating Humidity: 0% - 95%Storage Relative Humidity: 0% - 95%Minimum Operating Temperature: 32°F (0°C)Maximum Operating Temperature: 104°F (40°C)Sound Emission (A-Weighted): 55.5 dB(A)Thermal Dissipation: 96.70 BTU/hProduct Color: BlackHeight: 10.50" (266.70 mm)Width: 22" (558.80 mm)Depth: 19.70" (500.40 mm)Length: 24.13" (612.90 mm)Rack Height: 2UForm Factor: Tower/Rack ConvertibleWeight (Approximate): 37.19 kgEnergy Star: YesEnvironmentally Friendly: YesEnvironmental Certification: Limited Warranty: 3 YearAdditional Warranty Information: - Connected Equipment Guarantee: Lifetime
- Connected Equipment Guarantee:
- 400,000
[custom-specifications]
SpecificationsManufacturer: CyberPower Systems, Inc
Manufacturer Part Number: PR1500RTXL2UCN
Manufacturer Website Address: https://www.cyberpowersystems.com/
Brand Name: CyberPower
Product Line: Smart App Sinewave
Product Model: PR1500RTXL2UCN
Product Name: Smart App Sinewave PR1500RTXL2UCN 1500VA Tower/Rack Convertible UPS
Product Type: Line-interactive UPS
Technical InformationAVR: Yes
Plug/Connector Type: NEMA 5-15P
Receptacle Type: NEMA 5-15R
Receptacle Detail: 8 x NEMA 5-15R
Number of Battery & Surge Outlets: 8
Number of Critical Load Outlets: 4
Overload Protection: Yes
Cord Length: 10 ft
Transfer Time: 4 ms
EMI/RFI Noise Filter: Yes
Power DescriptionLoad Capacity (VA): 1.50 kVA
Load Capacity (Watt): 1.50 kW
Input Voltage: 120 V AC
Input Voltage Range: 70 V AC - 155 V AC
Output Voltage:
- 100 V AC
- 110 V AC
- 120 V AC
- 125 V AC
Input Frequency: 63 Hz
Output Frequency: 60 Hz
Waveform Type: Sine Wave
Surge Energy Rating: 2430 J
Circuit Breaker: Yes
Output Power Factor: 1
Display & GraphicsDisplay: LCD
ManagementNetwork Management:
- SNMP/HTTP Remote Monitoring
- Relay-MS Card
- Network Card
Alarm: Battery Mode
Controls/IndicatorsStatus Indicators:
LED Indicators:
Interfaces/PortsSerial Port: Yes
USB: Yes
EPO Port: Yes
USB (HID Compliant) Port: Yes
Battery InformationNumber of Batteries: 4
Battery Characteristics: Sealed
Battery Chemistry: Lead Acid
Battery Size: 12V
Battery Capacity: 9000 mAh
Backup/Run Time (Full Load): 6.50 Minute
Backup/Run Time (Half Load): 17.90 Minute
Hot Swappable: Yes
Typical Battery Recharge Time: 3 Hour
Replaceable Battery: Yes
Environmental ConditionsMaximum Operating Elevation: 9842.52 ft (3000000 mm)
Maximum Storage Elevation: 49209.32 ft (14999000 mm)
Storage Temperature: 5°F (-15°C) - 113°F (45°C)
Operating Humidity: 0% - 95%
Storage Relative Humidity: 0% - 95%
Minimum Operating Temperature: 32°F (0°C)
Maximum Operating Temperature: 104°F (40°C)
Sound Emission (A-Weighted): 55.5 dB(A)
Thermal Dissipation: 96.70 BTU/h
Physical CharacteristicsProduct Color: Black
Height: 10.50" (266.70 mm)
Width: 22" (558.80 mm)
Depth: 19.70" (500.40 mm)
Length: 24.13" (612.90 mm)
Rack Height: 2U
Form Factor: Tower/Rack Convertible
Weight (Approximate): 37.19 kg
MiscellaneousEnergy Star: Yes
Environmentally Friendly: Yes
Environmental Certification:
WarrantyLimited Warranty: 3 Year
Additional Warranty Information:
- Connected Equipment Guarantee: Lifetime
- Connected Equipment Guarantee:
- 400,000
[/custom-specifications]
[custom-options]
CyberPower UPS Systems RMCARD205 Hardware - Supported Protocols: TCP/IP, UDP, FTP, SCP, DHCP, DNS, SSH, Telnet, HTTP/HTTPS, SNMPv1/v3, IPv4/v6, NTP, SMTP, and Syslog - 2 x Network (RJ-45) Port(s)
