Datalogic PowerScan PD9630 - Cable Connectivity - 68.90" (1750.06 mm) Scan Distance - 1D, 2D - LED - Omni-directional - IP67, IP65 - - (PD9630-SRK2)
Write a Review
Datalogic
Datalogic PowerScan PD9630 - Cable Connectivity - 68.90" (1750.06 mm) Scan Distance - 1D, 2D - LED - Omni-directional - IP67, IP65 - - (PD9630-SRK2)
-
Business Pricing
Volume deals available
-
IT Experts
Consulting & support
-
Config Service
From PC to server
-
Canada Stocked
Toronto - Alberta - BC
- Whether you are a lefty or a righty, the symmetrically shaped mouse suits both
- USB Type A connectivity for a easy connection
- Optical LED for smoother movement and hassle-free performance
- Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes.
- Aztec Code
- China Han Xin Code
- Data Matrix
- MaxiCode
- Micro QR Code
- QR Code
- Dot code
- Australian Post
- China Post
- IMB
- Japanese Post
- KIX Post
- Planet Code
- Portuguese Post
- Postnet
- Royal Mail Code (RM4SCC)
- Swedish Post
- Digimarc Barcodes (PD9630-HP and PD9630-DC)
Connectivity Technology: Cable
Scanning Capability: 1D,2D
Barcode Symbology Supported: 1D:
Light Source: LED
Scan Pattern: Omni-directional
Scanner Range: Standard Range
Scanning Distance: 68.90" (1750.06 mm)
Cable Type Included: Serial
Field of View (Horizontal): 38°
Field of View (Vertical): 24°
Reading Angle (Skew): 52°
Reading Angle (Pitch): 52°
Reading Angle (Roll): 360°
Maximum Ambient Light: 100000 lux
Drop Specification: Withstands 50 drops from 2.5 m / 8.2 ft @ 20 °C / 68 °F
Withstands 50 drops from 2.0 m / 6.6 ft @ -20 °C / -4 °F
Minimum Print Contrast: 15%
Maximum Element Resolution (DataMatrix): 10 mil (0.25 mm)
Form Factor: Handheld
Rugged: Yes
Height: 7.50" (190.50 mm)
Width: 3.10" (78.74 mm)
Length: 5.50" (139.70 mm)
Weight (Approximate): 11.22 oz (318 g)
Ingress Protection (IP) Rating: IP67,IP65
Application/Usage: Manufacturing,Asset Tracking,Inventory,Warehouse,Logistics,Picking,Sorting,Industrial
- Laser-free design provides high-performance scanning without the risk of eye injury
- Perfect for applications that require direct association with a workstation or a notebook
[custom-specifications]
| Specifications | |
| Manufacturer | Datalogic S.p.A |
| Manufacturer Part Number | PD9630-SRK2 |
| Manufacturer Website Address | http://www.datalogic.com |
| Brand Name | Datalogic |
| Product Line | PowerScan |
| Product Series | 9600 |
| Product Model | PD9630 |
| Product Name | PowerScan PD9630 |
| Product Type | Barcode Scanner Kit |
| Technical Information | |
| Connectivity Technology | Cable |
| Scanning Capability | 1D,2D |
| Barcode Symbology Supported | 1D:
|
| Light Source | LED |
| Scan Pattern | Omni-directional |
| Scanner Range | Standard Range |
| Scanning Distance | 68.90" (1750.06 mm) |
| Cable Type Included | Serial |
| Field of View (Horizontal) | 38° |
| Field of View (Vertical) | 24° |
| Reading Angle (Skew) | 52° |
| Reading Angle (Pitch) | 52° |
| Reading Angle (Roll) | 360° |
| Maximum Ambient Light | 100000 lux |
| Drop Specification | Withstands 50 drops from 2.5 m / 8.2 ft @ 20 °C / 68 °F Withstands 50 drops from 2.0 m / 6.6 ft @ -20 °C / -4 °F |
| Minimum Print Contrast | 15% |
| Maximum Element Resolution (DataMatrix) | 10 mil (0.25 mm) |
| Physical Characteristics | |
| Form Factor | Handheld |
| Rugged | Yes |
| Height | 7.50" (190.50 mm) |
| Width | 3.10" (78.74 mm) |
| Length | 5.50" (139.70 mm) |
| Weight (Approximate) | 11.22 oz (318 g) |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP67,IP65 |
| Application/Usage | Manufacturing,Asset Tracking,Inventory,Warehouse,Logistics,Picking,Sorting,Industrial |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Manufacturer-Brochure
Additional-pdf1
Additional-pdf2
Additional-pdf3
Additional-pdf4
Additional-pdf5
Additional-pdf6
Additional-pdf7
[/custom-user-manual]
