Eaton 93PM 20kW Tower UPS - Tower - 480 V AC Input - 480 V AC Output - Yes - LCD Display (9PA02D0029E20R2)
Write a Review
Eaton
Eaton 93PM 20kW Tower UPS - Tower - 480 V AC Input - 480 V AC Output - Yes - LCD Display (9PA02D0029E20R2)
-
Business Pricing
Volume deals available
-
IT Experts
Consulting & support
-
Config Service
From PC to server
-
Canada Stocked
Toronto - Alberta - BC
- Whether you are a lefty or a righty, the symmetrically shaped mouse suits both
- USB Type A connectivity for a easy connection
- Optical LED for smoother movement and hassle-free performance
- Conserve valuable data center floor space with the compact footprint, internal battery back-up and optional internal maintenance bypass
- Grow effortlessly with the vertical scalability, reducing cost and unexpected future growth risks
- Reduce power and cooling OPEX through industry-leading energy efficiency; 99 percent efficiency with Energy Saver System (ESS) - Up to 97 percent efficiency in double-conversion mode
- Provides flexible configurability, maximizing deployment flexibility
- Track statistics on energy savings, battery time and outages profile your load and much more with the friendly graphical LCD touchscreen interface
- View system status from a distance with the green/ yellow/red LED light bars
- Supports optional communication cards that allow remote access via the HTTP(S), SNMP, MODBUS TCP/IP, Modbus RTU and BACnet IP protcols
- Manage your power devices in your physical or virtual environment with Eaton's Power Xpert® software and Intelligent Power™ Software Suite
- Increase uptime through 24x7 remote monitoring and reporting capabilities using Eaton's PredictPulse™ service that alerts technicians during critical events and results in faster resolutions when a problem is detected; learn more at Eaton.com/PredictPulse
Marketing Information:
The Eaton® 93PM UPS combines efficiency and reliability with an eye-catching design. A space-saving, scalable and flexible device that's as easy to deploy as it is to manage, it's the perfect three-phase white or grey space solution for today's data center.
Lowest TCO (total cost of ownership)
Easy deployment
Easy management
Advanced IT integration
Plug/Connector Type: Hard Wire 3-wire
Receptacle Type: Hard Wire 3-wire
Phase: Three Phase
Application/Usage: Data Center
Efficiency: 97%
Load Capacity (Watt): 20 kW
Input Voltage: 480 V AC
Output Voltage: 480 V AC
Input Frequency: 50 Hz,60 Hz
Output Power Factor: 0.8
Display: LCD
Network Management: HTTPS/SNMP/Modbus TCP-IP/Modbus RTU/BACnet IP
USB: Yes
EPO Port: Yes
DC System Voltage: 432 V DC
Form Factor: Tower
Height: 74" (1879.60 mm)
Width: 32" (812.80 mm)
Depth: 42" (1066.80 mm)
- Top & bottom cable entry Standard right-mounted wireway, supporting both top and bottom cable entry. This section contains all input and output connections for the UPS
- Communications and connectivity; Built-in device and host USB - Five alarm inputs and dedicated - EPO Alarm relay output - Four communication slots
- Color touchscreen LCD interface
- Serviceable redundant fan assembly
- Swappable power modules (50 kW) with independent control and power
- Soft start controls
- Static switch assembly
[custom-specifications]
| Specifications | |
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | 9PA02D0029E20R2 |
| Manufacturer Website Address | http://www.eaton.com/EatonCom/Markets/NorthAmerica |
| Brand Name | Eaton |
| Product Series | 93PM |
| Product Name | 93PM 20kW Tower UPS |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| Plug/Connector Type | Hard Wire 3-wire |
| Receptacle Type | Hard Wire 3-wire |
| Phase | Three Phase |
| Application/Usage | Data Center |
| Efficiency | 97% |
| Power Description | |
| Load Capacity (Watt) | 20 kW |
| Input Voltage | 480 V AC |
| Output Voltage | 480 V AC |
| Input Frequency | 50 Hz,60 Hz |
| Output Power Factor | 0.8 |
| Display & Graphics | |
| Display | LCD |
| Management | |
| Network Management | HTTPS/SNMP/Modbus TCP-IP/Modbus RTU/BACnet IP |
| Interfaces/Ports | |
| USB | Yes |
| EPO Port | Yes |
| Battery Information | |
| DC System Voltage | 432 V DC |
| Physical Characteristics | |
| Form Factor | Tower |
| Height | 74" (1879.60 mm) |
| Width | 32" (812.80 mm) |
| Depth | 42" (1066.80 mm) |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
User-Manual
Manufacturer-Brochure
[/custom-user-manual]
