EVGA 700BR Power Supply - Internal - 120 V AC, 230 V AC Input - 5 V DC, 12 V DC, 3.3 V DC Output - 700 W - 1 +12V Rails - 1 Fan(s) - - (100-BR-0700-K1)
Write a Review
EVGA
EVGA 700BR Power Supply - Internal - 120 V AC, 230 V AC Input - 5 V DC, 12 V DC, 3.3 V DC Output - 700 W - 1 +12V Rails - 1 Fan(s) - - (100-BR-0700-K1)
-
Business Pricing
Volume deals available
-
IT Experts
Consulting & support
-
Config Service
From PC to server
-
Canada Stocked
Toronto - Alberta - BC
- Whether you are a lefty or a righty, the symmetrically shaped mouse suits both
- USB Type A connectivity for a easy connection
- Optical LED for smoother movement and hassle-free performance
Specification Compliance: ATX12V/EPS12V
Efficiency: 85%
Number of Fans: 1
Modular: No
ATI CrossFire Supported: Yes
NVIDIA SLI Supported: Yes
Input Voltage: 120 V AC,230 V AC
Number of +12V Rails: 1
Output Voltage: 5 V DC,12 V DC,3.3 V DC
Output Voltage Detail: 5 V DC @ 20 A,12 V DC @ 58.3 A,5 V DC @ 3 A,12 V DC @ 300 mA,3.3 V DC @ 24 A
Output Current: 20 A,58.30 A,3 A,300 mA,24 A
Output Power: 700 W
Form Factor: Internal
Height: 3.35" (85 mm)
Width: 5.91" (150 mm)
Depth: 5.51" (140 mm)
Weight (Approximate): 1.81 kg
Country of Origin: China
Environmentally Friendly: Yes
Energy Efficiency Certification: 80 Plus Bronze
Energy Efficiency Compliance: Energy-related Products Directive Lot 6 (ErP Lot 6)
Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE),Restriction of Hazardous Substances (RoHS)
Limited Warranty: 3 Year
[custom-specifications]
| Specifications | |
| Manufacturer | EVGA Corporation |
| Manufacturer Part Number | 100BR0700K1 |
| Manufacturer Website Address | http://www.evga.com |
| Brand Name | EVGA |
| Product Series | BR |
| Product Model | 700BR |
| Product Name | 700BR Power Supply |
| Product Type | Power Supply |
| Technical Information | |
| Specification Compliance | ATX12V/EPS12V |
| Efficiency | 85% |
| Number of Fans | 1 |
| Modular | No |
| ATI CrossFire Supported | Yes |
| NVIDIA SLI Supported | Yes |
| Power Description | |
| Input Voltage | 120 V AC,230 V AC |
| Number of +12V Rails | 1 |
| Output Voltage | 5 V DC,12 V DC,3.3 V DC |
| Output Voltage Detail | 5 V DC @ 20 A,12 V DC @ 58.3 A,5 V DC @ 3 A,12 V DC @ 300 mA,3.3 V DC @ 24 A |
| Output Current | 20 A,58.30 A,3 A,300 mA,24 A |
| Output Power | 700 W |
| Physical Characteristics | |
| Form Factor | Internal |
| Height | 3.35" (85 mm) |
| Width | 5.91" (150 mm) |
| Depth | 5.51" (140 mm) |
| Weight (Approximate) | 1.81 kg |
| Miscellaneous | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Energy Efficiency Certification | 80 Plus Bronze |
| Energy Efficiency Compliance | Energy-related Products Directive Lot 6 (ErP Lot 6) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE),Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
[/custom-specifications]
Warranty Information
3 Year
