Grandstream HD IP Video Door System - 2 Megapixel - 150° Horizontal - 180° Vertical0.5 lux - Full-duplex - Door Entry (GDS3710)

Marketing Information

:

The GDS3710 is an IP Video Door System that also serves as a high-definition IP surveillance camera and IP intercom to offer facility access control and security monitoring for buildings of all sizes. This powerful IP Video Door System offers a 180-degree video viewing angle for wall-to-wall coverage, has a built-in RFID chip reader for secure keyless entry, includes a built-in microphone and speaker to support intercom functionality and offers alarm-in and alarm-out support for integration with existing security devices. The GDS3710 integrates with Grandstream's free management utility software, GDS Manager, allowing RFID card information, video feeds as well as the device itself to be fully managed by this software. By being ONVIF Profile S compliant, the GDS3710 can be integrated with any third party ONVIF compliant surveillance or recording solution. Powered by an advanced Image Sensor Processor (ISP) and state-of-the-art image algorithms, the GDS3710 delivers 1080p FHD video resolutions and offers exceptional performance in all lighting conditions. It features SIP/VoIP technology with 2-way audio and video streaming feeds loaded directly to smart phones, SIP endpoints and the GDS management software. The GDS3710 is equipped with integrated PoE for seamless installation, bright LEDs for illumination, motion detector for security protection, lighting control switch and more. The combination of the GDS3710, Grandstream's GXP21xx IP phones, GXV video phones and Grandstream Wave mobile app provide a complete solution for access control, video intercom, and security needs.

Communication Mode

: Full-duplex

Illumination

: 0.5 lux

Horizontal Viewing Angle

: 150°

Vertical Viewing Angle

: 180°

Input Voltage

: 12 V DC

Durability

:
• Vandal Resistant
• Weather Proof

Height

: 6.81" (173 mm)

Width

: 3.15" (80 mm)

Depth

: 1.42" (36 mm)

Weight (Approximate)

: 600 g

Application/Usage

: Door Entry

Environmentally Friendly

: Yes

Environmental Certification

: RoHS 2

Specifications
Manufacturer: Grandstream Networks, Inc
Manufacturer Part Number: GDS3710
Manufacturer Website Address: http://www.grandstream.com
Brand Name: Grandstream
Product Model: GDS3710
Product Name: HD IP Video Door System
Product Type: Video Door Phone Sub Station
Technical Information
Communication Mode: Full-duplex
Camera
Illumination: 0.5 lux
Horizontal Viewing Angle: 150°
Vertical Viewing Angle: 180°
Power Description
Input Voltage: 12 V DC
Physical Characteristics
Durability:

• Vandal Resistant
• Weather Proof

Height: 6.81" (173 mm)
Width: 3.15" (80 mm)
Depth: 1.42" (36 mm)
Weight (Approximate): 600 g
Miscellaneous
Application/Usage: Door Entry
Environmentally Friendly: Yes
Environmental Certification: RoHS 2
