- Get full control over access protection and ensure employees gain fast access with this card reader access device
- With proximity technology, get highly-secure access with outstanding and consistent performance
- An ideal choice for door security
Marketing Information: Cost-Effectively Transition to Advanced Technology
Kantech's ioSmart Smart Card Readers give customers an easy and powerful way to move from proximity cards to advanced smart card technology, whether they are using the popular Kantech ioProx solution or another proximity system.
Multi-technology readers provide the option to read both prox and smart cards allowing the customers to migrate at their pace.
High Level of Security
ioSmart readers provide end-to-end AES 128-bit encryption between the ioSmart card and ioSmart reader when connected to KT-400 and KT-1 controller over RS-485 and aforementioned controllers to EntraPass software over IP.
Versatile, Time-Saving Design
Unlike other solutions on the market that use restrictive, proprietary technology, ioSmart's open technology offers versatility. Based on MIFARE Plus smart technology for readers, and MIFARE Plus EV1 for credentials, ioSmart supports many different car formats, including HID® Prox. The reader can also be used with any access controller using Wiegand protocol.
To save installation time and money, ioSmart Smart Card Readers can be wired directly to standard door contacts and T.Rex devices rather than running the wires all the way to a controller.
ioSmart Smart Card Readers are available in single-gang or mullion models and can be installed in indoor or outdoor applications.
Identification Method: ProximityOperating Range: 2.01" (51 mm)Application/Usage: Ingress Protection (IP) Rating: IP55Serial: YesWiegand: YesInput Voltage: Height: 4.56" (115.80 mm)Width: 2.81" (71.50 mm)Depth: 0.97" (24.70 mm)Weight (Approximate): 170 gCompatibility: Compatible RS-485 Access Control Units:
Environmentally Friendly: YesLimited Warranty: Lifetime
[custom-specifications]
SpecificationsManufacturer: Johnson Controls
Manufacturer Part Number: KTSGMT2
Manufacturer Website Address: http://www.johnsoncontrols.com
Brand Name: Kantech
Product Line: ioSmart
Product Model: KT-MUL-MT
Product Name: ioSmart Smart Card Reader, Multi-technology, Mullion
Product Type: Card Reader Access Device
Technical InformationIdentification Method: Proximity
Operating Range: 2.01" (51 mm)
Application/Usage:
Ingress Protection (IP) Rating: IP55
Interfaces/PortsSerial: Yes
Wiegand: Yes
Power DescriptionInput Voltage:
Physical CharacteristicsHeight: 4.56" (115.80 mm)
Width: 2.81" (71.50 mm)
Depth: 0.97" (24.70 mm)
Weight (Approximate): 170 g
MiscellaneousCompatibility:
Compatible RS-485 Access Control Units: Environmentally Friendly: Yes
WarrantyLimited Warranty: Lifetime
[/custom-specifications]
