Marketing Information: The NETCOM2P is a plug on TCP/IP communication adaptor module that connects directly to Keyscan networked access control systems. The Keyscan NETCOM TCP/IP communication adaptor modules function as a fast and easy way to connect a Keyscan Access Control system to a LAN/WAN network. The adaptors plug onto the CIM for network communication or directly onto the control board for single access control unit applications.
- Where higher security is required for communication, use the NETCOM6P with AES Rijndael (NIST approved) encryption algorithm
- A user-defined encryption key, which can be can be 128 bits, 192 bits, or 256 bits, minimizes the possibility of communication breach
- Includes a Keyscan NETCOM Program Tool utility for custom installation programming
- Also available as an off-board module, NETCOM2 for legacy panels and select integrations
- Fast and easy installation for each ACU
- Requires Static IP addresses for proper operation
- Simplifies both installation and maintenance procedures
- Easy to program with included utility
Device Supported: Access Control SystemFeatures: - Programmable
- Easy Installation
Height: 1.63" (41.28 mm)Width: 1.94" (49.21 mm)Additional Information: TECHNICAL DATA:
- Input power through ACU: 140 mA, + ACU 130 mA = 270 mA
- Input power through CIM: 140 mA + CIM 150 mA = 290 mA
- Network interface: RJ45 10/100 Ethernet
- NETCOM6P: Available with AES Rijndael encryption
- NET6P-KHS (Keyscan Hosted Services only): DHCP IP set up; AES Rijndael encryption; Pre- configured to connect with Keyscan Servers
- Operating temperature: 5° to 70°C (41° to 158°F)
- Not suitable for Centrally Managed Access Control (CMAC) applications - use encrypted format (Part #: NETCOM6P) for CMAC applications or high security data transmission applications that require encryption
- Delivers multiple ACU communication to PC over a LAN/WAN (TCP/IP)
- Suitable for 10/100 Ethernet/Fast Ethernet applications
- Uses static IP address
Application/Usage: - Commercial
- Industrial
- Access Control
Compatibility: Communication Boards:
Certifications & Standards: - Agency approvals:
- Ethernet socket: Complies with Class B limits of EN 55022 : 1998;
- Direct and indirect ESD Complies with EN 55024 : 1998.
[custom-specifications]
SpecificationsManufacturer: dormakaba Holding
Manufacturer Part Number: NETCOM2P
Manufacturer Website Address: http://www.dormakaba.com
Brand Name: Keyscan
Product Line: NETCOM2P
Product Name: NETCOM2P TCP/IP Communication Adapter
Product Type: TCP/IP Communication Adapter
Technical InformationDevice Supported: Access Control System
Features:
- Programmable
- Easy Installation
Physical CharacteristicsHeight: 1.63" (41.28 mm)
Width: 1.94" (49.21 mm)
MiscellaneousAdditional Information:
TECHNICAL DATA:
- Input power through ACU: 140 mA, + ACU 130 mA = 270 mA
- Input power through CIM: 140 mA + CIM 150 mA = 290 mA
- Network interface: RJ45 10/100 Ethernet
- NETCOM6P: Available with AES Rijndael encryption
- NET6P-KHS (Keyscan Hosted Services only): DHCP IP set up; AES Rijndael encryption; Pre- configured to connect with Keyscan Servers
- Operating temperature: 5° to 70°C (41° to 158°F)
- Not suitable for Centrally Managed Access Control (CMAC) applications - use encrypted format (Part #: NETCOM6P) for CMAC applications or high security data transmission applications that require encryption
- Delivers multiple ACU communication to PC over a LAN/WAN (TCP/IP)
- Suitable for 10/100 Ethernet/Fast Ethernet applications
- Uses static IP address
Application/Usage:
- Commercial
- Industrial
- Access Control
Compatibility:
Communication Boards: Certifications & Standards:
- Agency approvals:
- Ethernet socket: Complies with Class B limits of EN 55022 : 1998;
- Direct and indirect ESD Complies with EN 55024 : 1998.
[/custom-specifications]
