Physical Characteristics |
|---|
| Color | Blue |
| Display | 4.3 inch IPS LCD Test Monitor with Touch Screen |
| Resolution (RGB) | 800 x 480 |
| Dimensions | 212 x 135.5 x 56.5mm |
| Operating Temperature | -10„ƒ to +50„ƒ |
| Operating Humidity | 30% to 90% |
Power |
|---|
| Power Output | 48V PoE Power Output, 24W (Max Power)
DC 12V/2A for camera |
| Battery | Built-in 7.4V Lithium Polymer Battery, 5000mAh
Working Time: 16 hours
Charging Time: 7~8 hours |
Performance |
|---|
| IP Camera Type | ONVIF |
| IP Discovery | Auto-scan the whole network segment of IP camera |
| Rapid ONVIF | Searches for camera quickly, auto log in and display image from the camera |
| Network Port | 10/100M Auto Adapt, RJ45 |
| Wi-Fi | Built in Wi-Fi, Speeds 150M, Display Wireless Camera Image |
| HD TVI Camera Test | Supports resolution of 1080p@30fps/25fps, 720p@60fps/50fps/30fps/25fps, Camera OSD menu controlled over coaxial cable |
| CVBS Video Signal Test | Supports PAL/NTSC |
| PTZ Control | Supports RS232/RS485 control, Baud 600-115200bps
Compatible with more than 30 protocols |
| Image Zoom | Supports 4 x zoom of the image display |
| Color Bar Generator | Output one channel of PAL/NTSC color bar video signal, for testing monitor / video cable (Red, Green, Blue, White and Black) |
| UTP Cable Tester | Tests UTP cable connection status and displays on screen |
| Data Monitor | Captures and analyzes the command data from controlling device |
| Network Test | IP Address Scan, Link Test, Ping Test, can search IP camera connection and other device's IP addresses |
| PoE/PSE Test | Measures PoE Switch or PSE power supply voltage and cable connection status |
| Auto Power Off | Can adjust from 5 to 30 minutes |
| Supports | Image Screen Snapshot
Record/Save/View/Record and Playback
|
Connectors |
|---|
| Inputs | 1 - BNC Input
1 - HDMI Input
1 - Micro SD port
1 - Audio Input
1 - DC 12V Input
1 - RS232/RS845 ports |
| Outputs | 1 - BNC Output
1 - HDMI Output
1 - Audio Output
1 - DC 5V 2A USB A Output |
| Ethernet | 1 - PSE Input
1 - LAN
1 - UTP/SCAN |
Packaging Information |
|---|
| Packaging Contents | 1 - Network Camera Tester (with 7.4V 5000mAh Polymer Lithium Ion Battery)
1 - Network Cable Tester
1 - BNC Cable
1 - RS485 Cable
1 - Audio Cable
1 - Multi-Meter Test Leads (One Pair of Red and Black)
1 - Power Adapter DC12V/2A
1 - Output Power Cable
1 - Tool Bag
1 - Safety Cord
1 - 8GB Micro SD Card
1 - User Manual |
| Product Weight | 1.65 lbs [0.75kg] |
