- USB to RS-232 DB9 Serial Adapter (Prolific PL2303HX Rev D Chipset)
- Driver CD
- Quick Installation Guide
Marketing Information: Features a Prolific PL2303GT chipset for the best combination of performance and wide driver support. Drivers available for Windows 11, 10, 8.1, 8. 7, and Vista through Windows Update or downloaded from our website, macOS and Linux rely on embedded serial port drivers for modern operating systems. Not compatible with ARM-based Windows (MS Surface).
Compatibility
Works with devices with RS-232 serial ports like: other PCs with RS-232 ports, Bluetooth serial adapters, PDAs, GPS receivers, routers, firewalls, modems, printers, embedded character displays, scan tools, sonar units, embedded boards, etc. Works with software like: HyperTerminal, TeraTerm, WinDBG, all open source serial software on Linux, etc.
Connector compatibility note
The DB9 DTE male connector with retention screws. NULL Modem or straight through serial adapter cables may be required for connecting to some devices.
Updated
This adapter uses the latest Prolific PL2303GT chipset with a robust molded plastic adapter end and 2-foot USB cable.
Cable Type: Serial/USB
Cable Length: 2 ft
Connector Type on First End: USB Type A - Male
Connector on First End Details: 1 x USB Type A - Male
Connector Type on Second End: DB-9 RS-232 Serial - Male
Connector on Second End Details: 1 x 9-pin DB-9 RS-232 Serial - Male
Device Supported: PDA,GPS,Router,Modem,Printer,Network Firewall,Plotter,Label/Receipt Printer,Handheld Terminal,Computer
Data Transfer Rate: 230 kbit/s
Features: Screw Lock,Plug & Play
Package Contents:
Country of Origin: China
Limited Warranty: 2 Year
- USB TO RS232 SERIAL - Connect legacy DB-9 serial communications devices to a modern computer with USB
- LEGACY SUPPORT - Add a 9-pin DB9 RS-232 serial port to any modern computer, replaces built-in or PCIe serial adapters, recommended for use with a serial cable or NULL modem cable
- FLEXIBLE - Programmable baud rate from 75 bits per second to 128,000 bits per second. Plug-and-play creation of a COM port. Powered by USB; no external power needed
- COMPATIBLE - Genuine Prolific PL-2303HXD Chipset for widest possible compatibility with Windows (11, 10, 8.x, 7, Vista, and XP), Mac, Linux, and other platforms
- 2 YEAR WARRANTY - We love our Plugable products, and hope you will too. All of our products are backed with a 2-year limited parts and labor warranty as well as Seattle-based email support
[custom-specifications]
Specifications | |
Manufacturer | Plugable Technologies |
Manufacturer Part Number | PL2303-DB9 |
Manufacturer Website Address | http://www.plugable.com |
Brand Name | Plugable |
Product Name | USB to Serial Adapter Compatible with Windows, Mac, Linux |
Packaged Quantity | 1 |
Product Type | Data Transfer Cable |
Technical Information | |
Cable Type | Serial/USB |
Cable Length | 2 ft |
Connector Type on First End | USB Type A - Male |
Connector on First End Details | 1 x USB Type A - Male |
Connector Type on Second End | DB-9 RS-232 Serial - Male |
Connector on Second End Details | 1 x 9-pin DB-9 RS-232 Serial - Male |
Device Supported | PDA,GPS,Router,Modem,Printer,Network Firewall,Plotter,Label/Receipt Printer,Handheld Terminal,Computer |
Data Transfer Rate | 230 kbit/s |
Features | Screw Lock,Plug & Play |
Miscellaneous | |
Package Contents |
|
Country of Origin | China |
Warranty | |
Limited Warranty | 2 Year |
[/custom-specifications]
Warranty Infomartion
2 Year
