SDC ACM-1 Access Control Module - 24 V DC (ACM-1)

Marketing Information:

Door control relay modules ensure compatibility of access hardware components and simplify system installation and troubleshooting. Different modules may be specified for one power supply.

The isolated relay design allows small gauge cable runs of 22 gauge wire up to 1000 feet from the trigger device to the module.

Application/Usage: Door

Input Voltage: 24 V DC

Height: 4.25" (107.95 mm)

Width: 3.25" (82.55 mm)

Package Contents:

• ACM-1 Access Control Module
• 1 x SPDT Voltage Output
• 1 x SPDT Dry Contact. 5A @30VDC Resistive
• 8 x SPDT Trigger Inputs (4-NC,4-NO)
• 1 x LED Status Indicator
