Sharp AQOUS BOARD 4WB86FT5U Collaboration Display - 86" LCD - Infrared (IrDA) - Touchscreen - 3840 x 2160 - LED - 350 cd/m² - - - (4WB86FT5U)

• 86" Class (85.6" diagonal) Screen Size Brilliant 4K-Ultra High Definition (3840 x 2160) LCD Display Streamlined Design using Direct LED Backlighting HDR10 Wireless casting capability Built-in 8W per Channel Stereo Audio System 20-Point Multi-Touch Screen 3-Year Limited Warranty Built-in Digital Tuner RS-232C control capability User-Friendly Sharp Pen Software

Marketing Information:

Sharp's 4WB series AQUOS BOARD® interactive displays add interoperability and collaboration to any environment.

Sharp 4WB86FT5U - 86" Class (85.6" diagonal) AQUOS BOARD® interactive display enables collaboration and communication in the workplace, classroom and virtually anywhere through precise 20-point multi-touch functionality and versatile connectivity. It is specified to continuously operate for up to 16-hours a day, 7-days a week, providing reliable performance in a classroom or office. A powerful RS-232C and LAN command set facilitates flexible wireless remote control from connected devices. Wireless screen casting** and an HTML5 browser allow for viewing various types of content onto the large format display.

This display of 4WB series includes integrated solutions such as:

HTML5 Browser App with an HTML5 browser, you can start signage quickly, leveraging your web-based content, while making your business or classroom more efficient.

Professional Command Control RS-232C and LAN command set enables flexible remote control from connected devices.

Multi OS Support. Plug & Play, your computer automatically recognizes the 4WB series displays when connected, without a complicated driver to install.

Public mode prevents unwanted adjustments by people in public locations such as classrooms and office spaces.

Screen Mirroring App, cast your personal device screen in real-time by mirroring your complete screen, including photos, videos, apps and websites onto the large format display.


Screen Size: 86"
Display Screen Type: LCD
Display Screen Technology: TFT LCD
Backlight Technology: LED
Screen Mode: 4K UHD
Screen Resolution: 3840 x 2160
Scan Format: 2160p
Contrast Ratio: 1,200:1
Brightness: 350 cd/m²
Horizontal Viewing Angle: 178°
Vertical Viewing Angle: 178°
Touchscreen: Yes
Multi-touch Screen: Yes
Number of Touch Points: 20
Touchscreen Technology: Infrared (IrDA)
Speakers: Yes
Number of Speakers: 2.0
RMS Output Power: 16 W
Ethernet: Yes
Wireless LAN: Yes
HDMI: Yes
Total Number of USB Ports: 2
USB: Yes
Network (RJ-45): Yes
Audio Line In: Yes
VGA: Yes
Serial: Yes
Software Included:

User-Friendly Sharp Pen Software


Input Voltage: 120 V AC
Power Consumption: 380 W
VESA Mount Compatible: Yes
VESA Mount Standard: 600 x 400
Height: 45" (1143 mm)
Width: 77" (1955.80 mm)
Depth: 4.20" (106.68 mm)
Weight (Approximate): 68.22 kg
Package Contents:
• AQOUS BOARD 4WB86FT5U Collaboration Display
• Remote Control Unit
• 2 x AAA size battery
• Quick Setup Guide
• RS-232C Conversion Cable
• USB-C to USB-A Conversion Adapter
• 2 x Touch Pen
• External IR Receiver
• USB Flash Drive

Country of Origin: Mexico
Limited Warranty: 3 Year

User-Friendly Sharp Pen Software
