StarTech.com 500ft VGA KVM Over IP Extender - PS/2 & USB Host - KVM Console Over CAT5 Ethernet for Multiple Servers / Computers - a & (SV565UTPU)
Write a Review
StarTech.com
StarTech.com 500ft VGA KVM Over IP Extender - PS/2 & USB Host - KVM Console Over CAT5 Ethernet for Multiple Servers / Computers - a & (SV565UTPU)
-
Business Pricing
Volume deals available
-
IT Experts
Consulting & support
-
Config Service
From PC to server
-
Canada Delivery
UPS, FedEx, Purolator
- Whether you are a lefty or a righty, the symmetrically shaped mouse suits both
- USB Type A connectivity for a easy connection
- Optical LED for smoother movement and hassle-free performance
- USB VGA KVM Console/Extender
- 2 x 6 ft 2-in-1 USB VGA KVM Cables
- 8 x Rubber Feet
- 1 x Power Adapter
- 1 x Instuction Manual
Connectivity Technology: Wired
KVM Technology: Analog
Number of Computers Supported: 2
Number of Local Users Supported: 1
Number of Remote Users Supported: 1
Maximum Operating Distance: 500 ft (152400 mm)
Graphic Mode: XGA
Maximum Video Resolution: 1024 x 768
Network (RJ-45): Yes
USB: Yes
VGA: Yes
Number of VGA Ports: 4
Number of Network (RJ-45) Ports: 2
Number of USB Ports: 4
Input Voltage: 120 V AC,240 V AC
Input Voltage Range: 110V AC to 240V AC
Power Consumption: 5.40 W
Color Family: Black
Product Color: Black
Form Factor: Desktop
Transmitter Height: 0.80" (20.32 mm)
Transmitter Width: 6.10" (154.94 mm)
Receiver Height: 0.80" (20.32 mm)
Receiver Width: 6.10" (154.94 mm)
Transmitter Weight (Approximate): 1.32 lb (600 g)
Receiver Weight (Approximate): 1.32 lb (600 g)
Package Contents:
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin: Taiwan
TAA Compliant: Yes
Limited Warranty: 2 Year
Additional Warranty Information: This product is TAA compliant and backed by a Startech.com 2-year warranty with free lifetime technical support.
- REMOTE OPERATION: Use the VGA over CAT5 extender to control a USB & VGA KVM or PC up to 500ft (150m) away; Supports hotkey commands, auto-switching between host and remote unit or dedicated control
- COST-EFFECTIVE KVM EXTENSION: The KVM Extender provides a cost-effective way to convert existing standard KVM units into remote-access hardware, extending the capabilities of your hardware
- FLEXIBLE CONFIGURATION: KVM console extender can be used with a single computer or connected to an existing KVM switch; Offers broad support for USB keyboards, mice, and even most combo/wireless configurations
- EASY INSTALLATION: Plug and play KVM over Ethernet extender is easy to install using industry-standard UTP network cables and is OS independent, requiring no software or drivers to install
- THE IT PRO'S CHOICE: Designed and built for IT Professionals, this CAT5 KVM extender is backed for 2-Years, including free lifetime 24/5 multi-lingual technical assistance
[custom-specifications]
| Specifications | |
| Manufacturer | StarTech.com |
| Manufacturer Part Number | SV565UTPU |
| Manufacturer Website Address | http://www.startech.com |
| Brand Name | StarTech.com |
| Product Model | SV565UTPU |
| Product Name | USB VGA KVM Console Extender over CAT5 UTP - 500 ft |
| Packaged Quantity | 1 Kit |
| Product Type | KVM Console/Extender |
| Technical Information | |
| Connectivity Technology | Wired |
| KVM Technology | Analog |
| Number of Computers Supported | 2 |
| Number of Local Users Supported | 1 |
| Number of Remote Users Supported | 1 |
| Maximum Operating Distance | 500 ft (152400 mm) |
| Video | |
| Graphic Mode | XGA |
| Maximum Video Resolution | 1024 x 768 |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| USB | Yes |
| VGA | Yes |
| Number of VGA Ports | 4 |
| Number of Network (RJ-45) Ports | 2 |
| Number of USB Ports | 4 |
| Power Description | |
| Input Voltage | 120 V AC,240 V AC |
| Input Voltage Range | 110V AC to 240V AC |
| Power Consumption | 5.40 W |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Desktop |
| Transmitter Height | 0.80" (20.32 mm) |
| Transmitter Width | 6.10" (154.94 mm) |
| Receiver Height | 0.80" (20.32 mm) |
| Receiver Width | 6.10" (154.94 mm) |
| Transmitter Weight (Approximate) | 1.32 lb (600 g) |
| Receiver Weight (Approximate) | 1.32 lb (600 g) |
| Miscellaneous | |
| Package Contents | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | 2 Year |
| Additional Warranty Information | This product is TAA compliant and backed by a Startech.com 2-year warranty with free lifetime technical support. |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
User-Manual
Manufacturer-Brochure
[/custom-user-manual]
Warranty Information
2 Year
