StarTech.com 500ft VGA KVM Over IP Extender - PS/2 & USB Host - KVM Console Over CAT5 Ethernet for Multiple Servers / Computers - a & (SV565UTPU)
- USB VGA KVM Console/Extender
- 2 x 6 ft 2-in-1 USB VGA KVM Cables
- 8 x Rubber Feet
- 1 x Power Adapter
- 1 x Instuction Manual
Marketing Information:
The SV565UTPU USB VGA KVM Console Extender over CAT5 UTP (500 ft) lets you control a server, computer or multiple computers (connected through KVM Switch) over a standard Cat5 or Cat6 UTP network cable connection, at distances of up to 500 ft (150 m) away. PC connection cables are included with this product for a ready out of the box solution.
You can use your existing keyboard, mouse, and monitor to access both the server room and your office computer, saving space and avoiding the need for a dedicated remote console by allowing you to switch between workstation view and KVM view at the remote location.
This product is TAA compliant and backed by a Startech.com 2-year warranty with free lifetime technical support.
Connectivity Technology: Wired
KVM Technology: Analog
Number of Computers Supported: 2
Number of Local Users Supported: 1
Number of Remote Users Supported: 1
Maximum Operating Distance: 500 ft (152400 mm)
Graphic Mode: XGA
Maximum Video Resolution: 1024 x 768
Network (RJ-45): Yes
USB: Yes
VGA: Yes
Number of VGA Ports: 4
Number of Network (RJ-45) Ports: 2
Number of USB Ports: 4
Input Voltage: 120 V AC,240 V AC
Input Voltage Range: 110V AC to 240V AC
Power Consumption: 5.40 W
Color Family: Black
Product Color: Black
Form Factor: Desktop
Transmitter Height: 0.80" (20.32 mm)
Transmitter Width: 6.10" (154.94 mm)
Receiver Height: 0.80" (20.32 mm)
Receiver Width: 6.10" (154.94 mm)
Transmitter Weight (Approximate): 600 g
Receiver Weight (Approximate): 600 g
Package Contents:
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin: Taiwan
TAA Compliant: Yes
Limited Warranty: 2 Year
Additional Warranty Information: This product is TAA compliant and backed by a Startech.com 2-year warranty with free lifetime technical support.
- REMOTE OPERATION: Use the VGA over CAT5 extender to control a USB & VGA KVM or PC up to 500ft (150m) away; Supports hotkey commands, auto-switching between host and remote unit or dedicated control
- COST-EFFECTIVE KVM EXTENSION: The KVM Extender provides a cost-effective way to convert existing standard KVM units into remote-access hardware, extending the capabilities of your hardware
- FLEXIBLE CONFIGURATION: KVM console extender can be used with a single computer or connected to an existing KVM switch; Offers broad support for USB keyboards, mice, and even most combo/wireless configurations
- EASY INSTALLATION: Plug and play KVM over Ethernet extender is easy to install using industry-standard UTP network cables and is OS independent, requiring no software or drivers to install
- THE IT PRO'S CHOICE: Designed and built for IT Professionals, this CAT5 KVM extender is backed for 2-Years, including free lifetime 24/5 multi-lingual technical assistance
[custom-specifications]
| Specifications | |
|---|---|
| Manufacturer | StarTech.com |
| Manufacturer Part Number | SV565UTPU |
| Manufacturer Website Address | http://www.startech.com |
| Brand Name | StarTech.com |
| Product Model | SV565UTPU |
| Product Name | USB VGA KVM Console Extender over CAT5 UTP - 500 ft |
| Packaged Quantity | 1 |
| Packaged Quantity Condition | Kit |
| Product Type | KVM Console/Extender | Technical Information |
| Connectivity Technology | Wired |
| KVM Technology | Analog |
| Number of Computers Supported | 2 |
| Number of Local Users Supported | 1 |
| Number of Remote Users Supported | 1 |
| Maximum Operating Distance | 500 ft (152400 mm) | Video |
| Graphic Mode | XGA |
| Maximum Video Resolution | 1024 x 768 | Interfaces/Ports |
| Network (RJ-45) | Yes |
| USB | Yes |
| VGA | Yes |
| Number of VGA Ports | 4 |
| Number of Network (RJ-45) Ports | 2 |
| Number of USB Ports | 4 | Power Description |
| Input Voltage | 120 V AC,240 V AC |
| Input Voltage Range | 110V AC to 240V AC |
| Power Consumption | 5.40 W | Physical Characteristics |
| Color Family | Black |
| Product Color | Black |
| Form Factor | Desktop |
| Transmitter Height | 0.80" (20.32 mm) |
| Transmitter Width | 6.10" (154.94 mm) |
| Receiver Height | 0.80" (20.32 mm) |
| Receiver Width | 6.10" (154.94 mm) |
| Transmitter Weight (Approximate) | 600 g |
| Receiver Weight (Approximate) | 600 g | Miscellaneous |
| Package Contents | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | Taiwan |
| TAA Compliant | Yes | Warranty |
| Limited Warranty | 2 Year |
| Additional Warranty Information | This product is TAA compliant and backed by a Startech.com 2-year warranty with free lifetime technical support. |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
User-Manual
Manufacturer-Brochure
[/custom-user-manual]
