Supermicro PWS-505P-1H Power Supply - Rack-mountable - 3.3 V DC, 5 V DC, 12 V DC Output - 500 W (PWS-505P-1H)

Marketing Information:

The Supermicro PWS-505P-1H is capable of 500W output power at high efficiency. Enjoy the simplicity of active power factor correction (PFC) and automatically correct AC input for a full range of voltages and a quiet fan to keep it cool under heavy loads. This power supply is designed to not only provide you reliable power to your Supermicro 1U server but also protects it from over voltage, over current and short circuiting via protective circuitry embedded into the unit. All materials contained comply with RoHS requirements and is certified by Supermicro.

Specification Compliance: ATX12V/EPS12V

Output Voltage: 3.3 V DC,5 V DC,12 V DC

Output Current: 12 A,15 A,41 A,4 A

Output Power: 500 W

Form Factor: Rack-mountable

Height: 1.57" (40 mm)

Width: 7.09" (180 mm)

Depth: 3.94" (100 mm)

Environmentally Friendly: Yes

Energy Efficiency Certification: 80 Plus Platinum

Limited Warranty: 3 Year
