TP-Link Omada SG3452XMPP Ethernet Switch - 48 Ports - Manageable - Gigabit Ethernet - 10/100/1000Base-T, 10GBase-X - 3 Layer Supported (SG3452XMPP)
- 48× Gigabit RJ45 Ports (8× PoE++, 40× PoE+)
- 4× 10 Gbps SFP+ Slots
- 750 W Total PoE Budget (Max 90 W for Each PoE++ Port)
- Centralized Management
- Omada App
- Zero-Touch Provisioning
- Ethernet Ring Protection Switching
- Static Routing
- Access Points
- PTZ HD IP Cameras with Heaters
- Smart Building Lighting
- Audio System
- Thin Clients
- Omada SG3452XMPP Ethernet Switch
- Power Cord
- Quick Installation Guide
- Rackmount Kit
- Rubber Feet
Marketing Information:
Empowering the High-Power Devices with Gigabit PoE++ Ports
8× Gigabit PoE++ RJ45 Ports
40× Gigabit PoE+ RJ45 Ports
Budget Up to 90W per PoE++ Port
Total 750W PoE Power
Easily Build a Whole 10G Multi-gigabit Network
Features: Intelligent monitoring,Loop Protection,Zero-Touch Provisioning (ZTP)
Total Number of Network Ports: 48
Network (RJ-45): Yes
Modular: Yes
Port/Expansion Slot Details: 40 x Gigabit Ethernet PoE+,8 x Gigabit Ethernet PoE++,4 x 10 Gigabit Ethernet Expansion Slot
Media Type Supported: Twisted Pair,Optical Fiber
Ethernet Technology: Gigabit Ethernet
Network Technology: 10/100/1000Base-T,10GBase-X
Total Number of Expansion Slots: 4
Expansion Slot Type: SFP+
Number of SFP+ Slots: 4
Layer Supported: 3
Networking Standards: IEEE 802.3af,IEEE 802.3bt,IEEE 802.3at,IEEE 802.1ab,IEEE 802.1x,IEEE 802.1Q,IEEE 802.3x,IEEE 802.3ah,IEEE 802.3i,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z,IEEE 802.3ae,IEEE 802.3ad,IEEE 802.1D,IEEE 802.1w,IEEE 802.1s,IEEE 802.1p
Manageable: Yes
PoE (RJ-45) Port: Yes
PoE Budget: 750 W
Input Voltage: 120 V AC,230 V AC
Power Source: Power Supply
Power Consumption: 913.40 W
Product Material: Metal
Compatible Rack Unit: 1U
Form Factor: Rack-mountable,Standalone
Height: 1.70" (43.18 mm)
Width: 17.30" (439.42 mm)
Depth: 13" (330.20 mm)
Package Contents:
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
- 4× 10 Gbps SFP+ slots
- 8× Gigabit 802.af/at/bt PoE++ ports (Max 90 W PoE budget for each port)
- 40× Gigabit 802.3af/at PoE+ ports (Max 30 W budget for each port)
- 750 W total PoE budget
- Centralized cloud management via the web or the Omada app
- Standalone management via web, CLI, SNMP, and RMON
- Static Routing helps route internal traffic for higher efficiency
- VLAN, ACL, QoS, IGMP Snooping, OAM, and DDM
- ERPS supports rapid protection and recovery in a ring topology
- Durable metal casing and rack-mountable design
[custom-specifications]
| Specifications | |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | SG3452XMPP |
| Manufacturer Website Address | http://www.tp-link.com |
| Brand Name | TP-Link |
| Product Line | Omada |
| Product Model | SG3452XMPP |
| Product Name | Omada SG3452XMPP Ethernet Switch |
| Product Type | Ethernet Switch |
| Technical Information | |
| Features | Intelligent monitoring,Loop Protection,Zero-Touch Provisioning (ZTP) |
| Interfaces/Ports | |
| Total Number of Network Ports | 48 |
| Network (RJ-45) | Yes |
| Modular | Yes |
| Port/Expansion Slot Details | 40 x Gigabit Ethernet PoE+,8 x Gigabit Ethernet PoE++,4 x 10 Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,10GBase-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 4 |
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 4 |
| Network & Communication | |
| Layer Supported | 3 |
| Networking Standards | IEEE 802.3af,IEEE 802.3bt,IEEE 802.3at,IEEE 802.1ab,IEEE 802.1x,IEEE 802.1Q,IEEE 802.3x,IEEE 802.3ah,IEEE 802.3i,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z,IEEE 802.3ae,IEEE 802.3ad,IEEE 802.1D,IEEE 802.1w,IEEE 802.1s,IEEE 802.1p |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 750 W |
| Input Voltage | 120 V AC,230 V AC |
| Power Source | Power Supply |
| Power Consumption | 913.40 W |
| Physical Characteristics | |
| Product Material | Metal |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable,Standalone |
| Height | 1.70" (43.18 mm) |
| Width | 17.30" (439.42 mm) |
| Depth | 13" (330.20 mm) |
| Miscellaneous | |
| Package Contents |
|
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
